Metric Pilot Bore Timing Pulleys
-
Aluminium Pulley T5/26-2 For 25mm Belt (36T5/26-2)
Timing Pulleys T5 for 25mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T5/26-2 For 25mm Belt (36T5/26-2) Part No. 7802-156 Code 36T5/26-2 Type 1F No. teeth 26 De 40.6 Dp 41.4 Df 44 Dm 26 F 30 L 36 Bore (d) 8 Max. bore 25 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£7.25
-
Aluminium Pulley T5/27-2 For 25mm Belt (36T5/27-2)
Timing Pulleys T5 for 25mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T5/27-2 For 25mm Belt (36T5/27-2) Part No. 7802-157 Code 36T5/27-2 Type 1F No. teeth 27 De 42.2 Dp 43 Df 48 Dm 30 F 30 L 36 Bore (d) 8 Max. bore 27 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£7.40
-
Aluminium Pulley T5/28-2 For 25mm Belt (36T5/28-2)
Timing Pulleys T5 for 25mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T5/28-2 For 25mm Belt (36T5/28-2) Part No. 7802-158 Code 36T5/28-2 Type 1F No. teeth 28 De 43.8 Dp 44.6 Df 48 Dm 32 F 30 L 36 Bore (d) 8 Max. bore 29 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£7.95
-
Aluminium Pulley T5/30-2 For 25mm Belt (36T5/30-2)
Timing Pulleys T5 for 25mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T5/30-2 For 25mm Belt (36T5/30-2) Part No. 7802-159 Code 36T5/30-2 Type 1F No. teeth 30 De 47 Dp 47.8 Df 51 Dm 34 F 30 L 36 Bore (d) 8 Max. bore 33 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£8.58
-
Aluminium Pulley T5/32-2 For 25mm Belt (36T5/32-2)
Timing Pulleys T5 for 25mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T5/32-2 For 25mm Belt (36T5/32-2) Part No. 7802-160 Code 36T5/32-2 Type 1F No. teeth 32 De 50.1 Dp 50.9 Df 54 Dm 38 F 30 L 36 Bore (d) 8 Max. bore 37 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£9.63
-
Aluminium Pulley T5/36-2 For 25mm Belt (36T5/36-2)
Timing Pulleys T5 for 25mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T5/36-2 For 25mm Belt (36T5/36-2) Part No. 7802-161 Code 36T5/36-2 Type 1F No. teeth 36 De 56.5 Dp 57.3 Df 64 Dm 38 F 30 L 36 Bore (d) 8 Max. bore 42 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£11.30
-
Aluminium Pulley T5/40-2 For 25mm Belt (36T5/40-2)
Timing Pulleys T5 for 25mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T5/40-2 For 25mm Belt (36T5/40-2) Part No. 7802-162 Code 36T5/40-2 Type 1F No. teeth 40 De 62.9 Dp 63.7 Df 67 Dm 40 F 30 L 36 Bore (d) 8 Max. bore 47 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£12.78
-
Aluminium Pulley T5/42-2 For 25mm Belt (36T5/42-2)
Timing Pulleys T5 for 25mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T5/42-2 For 25mm Belt (36T5/42-2) Part No. 7802-163 Code 36T5/42-2 Type 1F No. teeth 42 De 66 Dp 66.9 Df 70 Dm 40 F 30 L 36 Bore (d) 8 Max. bore 50 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£13.85
-
Aluminium Pulley T5/44-0 For 25mm Belt (36T5/44-0)
Timing Pulleys T5 for 25mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T5/44-0 For 25mm Belt (36T5/44-0) Part No. 7802-164 Code 36T5/44-0 Type 2 No. teeth 44 De 69.2 Dp 70 Df Dm 45 F 30 L 36 Bore (d) 8 Max. bore 52 No. flanges 0 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£14.33
-
Aluminium Pulley T5/48-0 For 25mm Belt (36T5/48-0)
Timing Pulleys T5 for 25mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T5/48-0 For 25mm Belt (36T5/48-0) Part No. 7802-165 Code 36T5/48-0 Type 2 No. teeth 48 De 75.6 Dp 76.4 Df Dm 50 F 30 L 36 Bore (d) 8 Max. bore 60 No. flanges 0 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£16.20
-
Aluminium Pulley T5/60-0 For 25mm Belt (36T5/60-0)
Timing Pulleys T5 for 25mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T5/60-0 For 25mm Belt (36T5/60-0) Part No. 7802-166 Code 36T5/60-0 Type 2 No. teeth 60 De 94.7 Dp 95.5 Df Dm 65 F 30 L 36 Bore (d) 8 Max. bore 76 No. flanges 0 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£23.30
-
Aluminium Pulley T10/12T-2 For 16mm Belt (31T10/12-2)
Timing Pulleys T10 for 16mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T10/12T-2 For 16mm Belt (31T10/12-2) Part No. 7802-201 Code 31T10/12-2 Type 1F No. teeth 12 De 36.4 Dp 38.2 Df 42 Dm 28 F 21 L 31 Bore (d) 6 Max. bore 24 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£6.61
-
Aluminium Pulley T10/14T-2 For 16mm Belt (31T10/14-2)
Timing Pulleys T10 for 16mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T10/14T-2 For 16mm Belt (31T10/14-2) Part No. 7802-202 Code 31T10/14-2 Type 1F No. teeth 14 De 42.7 Dp 44.6 Df 48 Dm 32 F 21 L 31 Bore (d) 8 Max. bore 30 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£7.50
-
Aluminium Pulley T10/15T-2 For 16mm Belt (31T10/15-2)
Timing Pulleys T10 for 16mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T10/15T-2 For 16mm Belt (31T10/15-2) Part No. 7802-203 Code 31T10/15-2 Type 1F No. teeth 15 De 45.9 Dp 47.8 Df 51 Dm 32 F 21 L 31 Bore (d) 8 Max. bore 34 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£8.06
-
Aluminium Pulley T10/16T-2 For 16mm Belt (31T10/16-2)
Timing Pulleys T10 for 16mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T10/16T-2 For 16mm Belt (31T10/16-2) Part No. 7802-204 Code 31T10/16-2 Type 1F No. teeth 16 De 49.1 Dp 50.9 Df 54 Dm 35 F 21 L 31 Bore (d) 8 Max. bore 36 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£8.76
-
Aluminium Pulley T10/18T-2 For 16mm Belt (31T10/18-2)
Timing Pulleys T10 for 16mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T10/18T-2 For 16mm Belt (31T10/18-2) Part No. 7802-205 Code 31T10/18-2 Type 1F No. teeth 18 De 55.5 Dp 57.3 Df 60 Dm 40 F 21 L 31 Bore (d) 8 Max. bore 44 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£10.14
-
Aluminium Pulley T10/19T-2 For 16mm Belt (31T10/19-2)
Timing Pulleys T10 for 16mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T10/19T-2 For 16mm Belt (31T10/19-2) Part No. 7802-206 Code 31T10/19-2 Type 1F No. teeth 19 De 58.7 Dp 60.5 Df 66 Dm 44 F 21 L 31 Bore (d) 8 Max. bore 46 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£11.06
-
Aluminium Pulley T10/20T-2 For 16mm Belt (31T10/20-2)
Timing Pulleys T10 for 16mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T10/20T-2 For 16mm Belt (31T10/20-2) Part No. 7802-207 Code 31T10/20-2 Type 1F No. teeth 20 De 61.8 Dp 63.7 Df 66 Dm 46 F 21 L 31 Bore (d) 8 Max. bore 50 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£11.26
-
Aluminium Pulley T10/22T-2 For 16mm Belt (31T10/22-2)
Timing Pulleys T10 for 16mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T10/22T-2 For 16mm Belt (31T10/22-2) Part No. 7802-208 Code 31T10/22-2 Type 1F No. teeth 22 De 68.2 Dp 70 Df 75 Dm 52 F 21 L 31 Bore (d) 8 Max. bore 56 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£14.01
-
Aluminium Pulley T10/24T-2 For 16mm Belt (31T10/24-2)
Timing Pulleys T10 for 16mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T10/24T-2 For 16mm Belt (31T10/24-2) Part No. 7802-209 Code 31T10/24-2 Type 1F No. teeth 24 De 74.6 Dp 76.4 Df 83 Dm 58 F 21 L 31 Bore (d) 8 Max. bore 62 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£15.69
-
Aluminium Pulley T10/25T-2 For 16mm Belt (31T10/25-2)
Timing Pulleys T10 for 16mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T10/25T-2 For 16mm Belt (31T10/25-2) Part No. 7802-210 Code 31T10/25-2 Type 1F No. teeth 25 De 77.8 Dp 79.6 Df 83 Dm 60 F 21 L 31 Bore (d) 8 Max. bore 66 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£15.82
-
Aluminium Pulley T10/26T-2 For 16mm Belt (31T10/26-2)
Timing Pulleys T10 for 16mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T10/26T-2 For 16mm Belt (31T10/26-2) Part No. 7802-211 Code 31T10/26-2 Type 1F No. teeth 26 De 80.9 Dp 82.8 Df 87 Dm 60 F 21 L 31 Bore (d) 8 Max. bore 68 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£17.50
-
Aluminium Pulley T10/27T-2 For 16mm Belt (31T10/27-2)
Timing Pulleys T10 for 16mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T10/27T-2 For 16mm Belt (31T10/27-2) Part No. 7802-212 Code 31T10/27-2 Type 1F No. teeth 27 De 84.1 Dp 85.9 Df 91 Dm 60 F 21 L 31 Bore (d) 8 Max. bore 72 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£19.22
-
Aluminium Pulley T10/28T-2 For 16mm Belt (31T10/28-2)
Timing Pulleys T10 for 16mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T10/28T-2 For 16mm Belt (31T10/28-2) Part No. 7802-213 Code 31T10/28-2 Type 1F No. teeth 28 De 87.3 Dp 89.1 Df 93 Dm 60 F 21 L 31 Bore (d) 8 Max. bore 76 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£19.24
-
Aluminium Pulley T10/30T-2 For 16mm Belt (31T10/30-2)
Timing Pulleys T10 for 16mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T10/30T-2 For 16mm Belt (31T10/30-2) Part No. 7802-214 Code 31T10/30-2 Type 1F No. teeth 30 De 93.7 Dp 95.5 Df 97 Dm 60 F 21 L 31 Bore (d) 8 Max. bore 82 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£22.50
You have seen 100 out of 292 products
