XL Pilot Bore Timing Pulleys

•

  Aluminium Pulley 10T XL037 (P10XL037F)

  Timing Pulleys XL037 (0.200" / 5.08mm pitch) for 9.53mm (3/8") wide belt. Centre drilled or Pilot Bore in Aluminium with Zinc plated Steel Flanges or Phosphated Steel.Aluminium Pulley 10T XL037 (P10XL037F) Part No. 7801-201 Material P10XL037F Code(Aluminium) P10XL037F Type 1F No. Teeth 10 Dp 16 De 16 Df 23 Dm 10 F 14.3 L 20 Bore(d) – No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur

  Read more less

  £3.12

•

  Steel Pulley 10T XL037 (P10XL037FST)

  Timing Pulleys XL037 (0.200" / 5.08mm pitch) for 9.53mm (3/8") wide belt. Centre drilled or Pilot Bore in Aluminium with Zinc plated Steel Flanges or Phosphated Steel.Steel Pulley 10T XL037 (P10XL037FST) Part No. 7801-202 Material P10XL037FST Code(Aluminium) P10XL037FST Type 1F No. Teeth 10 Dp 16 De 16 Df 23 Dm 10 F 14.3 L 20 Bore(d) – No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur

  Read more less

  £2.25

•

  Aluminium Pulley 11T XL037 (P11XL037F)

  Timing Pulleys XL037 (0.200" / 5.08mm pitch) for 9.53mm (3/8") wide belt. Centre drilled or Pilot Bore in Aluminium with Zinc plated Steel Flanges or Phosphated Steel.Aluminium Pulley 11T XL037 (P11XL037F) Part No. 7801-203 Material P11XL037F Code(Aluminium) P11XL037F Type 1F No. Teeth 11 Dp 18 De 17 Df 23 Dm 10 F 14.3 L 20 Bore(d) – No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur

  Read more less

  £3.27

•

  Steel Pulley 11T XL037 (P11XL037FST)

  Timing Pulleys XL037 (0.200" / 5.08mm pitch) for 9.53mm (3/8") wide belt. Centre drilled or Pilot Bore in Aluminium with Zinc plated Steel Flanges or Phosphated Steel.Steel Pulley 11T XL037 (P11XL037FST) Part No. 7801-204 Material P11XL037FST Code(Aluminium) P11XL037FST Type 1F No. Teeth 11 Dp 18 De 17 Df 23 Dm 10 F 14.3 L 20 Bore(d) – No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur

  Read more less

  £2.23

•

  Aluminium Pulley 12T XL037 (P12XL037F)

  Timing Pulleys XL037 (0.200" / 5.08mm pitch) for 9.53mm (3/8") wide belt. Centre drilled or Pilot Bore in Aluminium with Zinc plated Steel Flanges or Phosphated Steel.Aluminium Pulley 12T XL037 (P12XL037F) Part No. 7801-205 Material P12XL037F Code(Aluminium) P12XL037F Type 1F No. Teeth 12 Dp 19 De 19 Df 25 Dm 10 F 14.3 L 20 Bore(d) – No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur

  Read more less

  £3.51

•

  Steel Pulley 12T XL037 (P12XL037FST)

  Timing Pulleys XL037 (0.200" / 5.08mm pitch) for 9.53mm (3/8") wide belt. Centre drilled or Pilot Bore in Aluminium with Zinc plated Steel Flanges or Phosphated Steel.Steel Pulley 12T XL037 (P12XL037FST) Part No. 7801-206 Material P12XL037FST Code(Aluminium) P12XL037FST Type 1F No. Teeth 12 Dp 19 De 19 Df 25 Dm 10 F 14.3 L 20 Bore(d) – No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur

  Read more less

  £2.38

•

  Aluminium Pulley 13T XL037 (P13XL037F)

  Timing Pulleys XL037 (0.200" / 5.08mm pitch) for 9.53mm (3/8") wide belt. Centre drilled or Pilot Bore in Aluminium with Zinc plated Steel Flanges or Phosphated Steel.Aluminium Pulley 13T XL037 (P13XL037F) Part No. 7801-207 Material P13XL037F Code(Aluminium) P13XL037F Type 1F No. Teeth 13 Dp 21 De 21 Df 25 Dm 10 F 14.3 L 20 Bore(d) – No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur

  Read more less

  £3.57

•

  Steel Pulley 13T XL037 (P13XL037FST)

  Timing Pulleys XL037 (0.200" / 5.08mm pitch) for 9.53mm (3/8") wide belt. Centre drilled or Pilot Bore in Aluminium with Zinc plated Steel Flanges or Phosphated Steel.Steel Pulley 13T XL037 (P13XL037FST) Part No. 7801-208 Material P13XL037FST Code(Aluminium) P13XL037FST Type 1F No. Teeth 13 Dp 21 De 21 Df 25 Dm 10 F 14.3 L 20 Bore(d) – No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur

  Read more less

  £2.28

•

  Aluminium Pulley 14T XL037 (P14XL037F)

  Timing Pulleys XL037 (0.200" / 5.08mm pitch) for 9.53mm (3/8") wide belt. Centre drilled or Pilot Bore in Aluminium with Zinc plated Steel Flanges or Phosphated Steel.Aluminium Pulley 14T XL037 (P14XL037F) Part No. 7801-209 Material P14XL037F Code(Aluminium) P14XL037F Type 1F No. Teeth 14 Dp 23 De 22 Df 28 Dm 15 F 14.3 L 20 Bore(d) – No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur

  Read more less

  £3.81

•

  Steel Pulley 14T XL037 (P14XL037FST)

  Timing Pulleys XL037 (0.200" / 5.08mm pitch) for 9.53mm (3/8") wide belt. Centre drilled or Pilot Bore in Aluminium with Zinc plated Steel Flanges or Phosphated Steel.Steel Pulley 14T XL037 (P14XL037FST) Part No. 7801-210 Material P14XL037FST Code(Aluminium) P14XL037FST Type 1F No. Teeth 14 Dp 23 De 22 Df 28 Dm 15 F 14.3 L 20 Bore(d) – No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur

  Read more less

  £2.40

•

  Aluminium Pulley 15T XL037 (P15XL037F)

  Timing Pulleys XL037 (0.200" / 5.08mm pitch) for 9.53mm (3/8") wide belt. Centre drilled or Pilot Bore in Aluminium with Zinc plated Steel Flanges or Phosphated Steel.Aluminium Pulley 15T XL037 (P15XL037F) Part No. 7801-211 Material P15XL037F Code(Aluminium) P15XL037F Type 1F No. Teeth 15 Dp 24 De 24 Df 28 Dm 15 F 14.3 L 20 Bore(d) – No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur

  Read more less

  £3.96

•

  Steel Pulley 15T XL037 (P15XL037FST)

  Timing Pulleys XL037 (0.200" / 5.08mm pitch) for 9.53mm (3/8") wide belt. Centre drilled or Pilot Bore in Aluminium with Zinc plated Steel Flanges or Phosphated Steel.Steel Pulley 15T XL037 (P15XL037FST) Part No. 7801-212 Material P15XL037FST Code(Aluminium) P15XL037FST Type 1F No. Teeth 15 Dp 24 De 24 Df 28 Dm 15 F 14.3 L 20 Bore(d) – No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur

  Read more less

  £2.55

•

  Aluminium Pulley 16T XL037 (P16XL037F)

  Timing Pulleys XL037 (0.200" / 5.08mm pitch) for 9.53mm (3/8") wide belt. Centre drilled or Pilot Bore in Aluminium with Zinc plated Steel Flanges or Phosphated Steel.Aluminium Pulley 16T XL037 (P16XL037F) Part No. 7801-213 Material P16XL037F Code(Aluminium) P16XL037F Type 1F No. Teeth 16 Dp 26 De 25 Df 32 Dm 16 F 14.3 L 20 Bore(d) – No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur

  Read more less

  £4.17

•

  Steel Pulley 16T XL037 (P16XL037FST)

  Timing Pulleys XL037 (0.200" / 5.08mm pitch) for 9.53mm (3/8") wide belt. Centre drilled or Pilot Bore in Aluminium with Zinc plated Steel Flanges or Phosphated Steel.Steel Pulley 16T XL037 (P16XL037FST) Part No. 7801-214 Material P16XL037FST Code(Aluminium) P16XL037FST Type 1F No. Teeth 16 Dp 26 De 25 Df 32 Dm 16 F 14.3 L 20 Bore(d) – No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur

  Read more less

  £3.03

•

  Aluminium Pulley 17T XL037 (P17XL037F)

  Timing Pulleys XL037 (0.200" / 5.08mm pitch) for 9.53mm (3/8") wide belt. Centre drilled or Pilot Bore in Aluminium with Zinc plated Steel Flanges or Phosphated Steel.Aluminium Pulley 17T XL037 (P17XL037F) Part No. 7801-215 Material P17XL037F Code(Aluminium) P17XL037F Type 1F No. Teeth 17 Dp 27 De 27 Df 32 Dm 20 F 14.3 L 20 Bore(d) – No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur

  Read more less

  £4.23

•

  Steel Pulley 17T XL037 (P17XL037FST)

  Timing Pulleys XL037 (0.200" / 5.08mm pitch) for 9.53mm (3/8") wide belt. Centre drilled or Pilot Bore in Aluminium with Zinc plated Steel Flanges or Phosphated Steel.Steel Pulley 17T XL037 (P17XL037FST) Part No. 7801-216 Material P17XL037FST Code(Aluminium) P17XL037FST Type 1F No. Teeth 17 Dp 27 De 27 Df 32 Dm 20 F 14.3 L 20 Bore(d) – No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur

  Read more less

  £3.03

•

  Aluminium Pulley 18T XL037 (P18XL037F)

  Timing Pulleys XL037 (0.200" / 5.08mm pitch) for 9.53mm (3/8") wide belt. Centre drilled or Pilot Bore in Aluminium with Zinc plated Steel Flanges or Phosphated Steel.Aluminium Pulley 18T XL037 (P18XL037F) Part No. 7801-217 Material P18XL037F Code(Aluminium) P18XL037F Type 1F No. Teeth 18 Dp 29 De 29 Df 35 Dm 20 F 14.3 L 20 Bore(d) – No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur

  Read more less

  £4.47

•

  Steel Pulley 18T XL037 (P18XL037FST)

  Timing Pulleys XL037 (0.200" / 5.08mm pitch) for 9.53mm (3/8") wide belt. Centre drilled or Pilot Bore in Aluminium with Zinc plated Steel Flanges or Phosphated Steel.Steel Pulley 18T XL037 (P18XL037FST) Part No. 7801-218 Material P18XL037FST Code(Aluminium) P18XL037FST Type 1F No. Teeth 18 Dp 29 De 29 Df 35 Dm 20 F 14.3 L 20 Bore(d) – No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur

  Read more less

  £3.13

•

  Aluminium Pulley 20T XL037 (P20XL037F)

  Timing Pulleys XL037 (0.200" / 5.08mm pitch) for 9.53mm (3/8") wide belt. Centre drilled or Pilot Bore in Aluminium with Zinc plated Steel Flanges or Phosphated Steel.Aluminium Pulley 20T XL037 (P20XL037F) Part No. 7801-219 Material P20XL037F Code(Aluminium) P20XL037F Type 1F No. Teeth 20 Dp 32 De 32 Df 38 Dm 24 F 14.3 L 22 Bore(d) – No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur

  Read more less

  £4.92

•

  Steel Pulley 20T XL037 (P20XL037FST)

  Timing Pulleys XL037 (0.200" / 5.08mm pitch) for 9.53mm (3/8") wide belt. Centre drilled or Pilot Bore in Aluminium with Zinc plated Steel Flanges or Phosphated Steel.Steel Pulley 20T XL037 (P20XL037FST) Part No. 7801-220 Material P20XL037FST Code(Aluminium) P20XL037FST Type 1F No. Teeth 20 Dp 32 De 32 Df 38 Dm 24 F 14.3 L 22 Bore(d) – No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur

  Read more less

  £3.83

•

  Aluminium Pulley 21T XL037 (P21XL037F)

  Timing Pulleys XL037 (0.200" / 5.08mm pitch) for 9.53mm (3/8") wide belt. Centre drilled or Pilot Bore in Aluminium with Zinc plated Steel Flanges or Phosphated Steel.Aluminium Pulley 21T XL037 (P21XL037F) Part No. 7801-221 Material P21XL037F Code(Aluminium) P21XL037F Type 1F No. Teeth 21 Dp 34 De 33 Df 38 Dm 24 F 14.3 L 22 Bore(d) – No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur

  Read more less

  £4.98

•

  Steel Pulley 21T XL037 (P21XL037FST)

  Timing Pulleys XL037 (0.200" / 5.08mm pitch) for 9.53mm (3/8") wide belt. Centre drilled or Pilot Bore in Aluminium with Zinc plated Steel Flanges or Phosphated Steel.Steel Pulley 21T XL037 (P21XL037FST) Part No. 7801-222 Material P21XL037FST Code(Aluminium) P21XL037FST Type 1F No. Teeth 21 Dp 34 De 33 Df 38 Dm 24 F 14.3 L 22 Bore(d) – No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur

  Read more less

  £3.80

•

  Aluminium Pulley 22T XL037 (P22XL037F)

  Timing Pulleys XL037 (0.200" / 5.08mm pitch) for 9.53mm (3/8") wide belt. Centre drilled or Pilot Bore in Aluminium with Zinc plated Steel Flanges or Phosphated Steel.Aluminium Pulley 22T XL037 (P22XL037F) Part No. 7801-223 Material P22XL037F Code(Aluminium) P22XL037F Type 1F No. Teeth 22 Dp 36 De 35 Df 41 Dm 25 F 14.3 L 22 Bore(d) 6 No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur

  Read more less

  £5.82

•

  Steel Pulley 22T XL037 (P22XL037FST)

  Timing Pulleys XL037 (0.200" / 5.08mm pitch) for 9.53mm (3/8") wide belt. Centre drilled or Pilot Bore in Aluminium with Zinc plated Steel Flanges or Phosphated Steel.Steel Pulley 22T XL037 (P22XL037FST) Part No. 7801-224 Material P22XL037FST Code(Aluminium) P22XL037FST Type 1F No. Teeth 22 Dp 36 De 35 Df 41 Dm 25 F 14.3 L 22 Bore(d) 6 No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur

  Read more less

  £4.33

•

  Aluminium Puleys 24T XL037 (P24XL037F)

  Timing Pulleys XL037 (0.200" / 5.08mm pitch) for 9.53mm (3/8") wide belt. Centre drilled or Pilot Bore in Aluminium with Zinc plated Steel Flanges or Phosphated Steel.Aluminium Puleys 24T XL037 (P24XL037F) Part No. 7801-225 Material P24XL037F Code(Aluminium) P24XL037F Type 1F No. Teeth 24 Dp 39 De 38 Df 44 Dm 30 F 14.3 L 22 Bore(d) 6 No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur

  Read more less

  £6.33
