Metric Gear Racks
-
Nylon 66 Rack MOD 1, 15x15x250mm
A 30% glass filled Nylon 66 moulded MOD 1 rack. Length 250mm, width 15mm, overall height 15mm, height to pitch line 14mm.
£16.64
-
Hostaform Hostaform Rack MOD 0.5, 4x4.5x250mm
White Plastic Mod 0.5 Rack 4x4.5x250mm. Specification A MOD 0.5 rack made from POM. MOD: 0.5 Width: 4mm Height: 4.5mm Length: 250mm
£2.50
-
Hostaform Hostaform Rack MOD 0.5, 4x6x250mm
White Plastic Mod 0.5 Rack 4x6x250mm. Specification A MOD 0.5 rack made from POM. MOD: 0.5 Width: 4mm Height: 6mm Length: 250mm
£2.67
-
Hostaform Hostaform MOD 0.7 Rack 6x6.7x250mm (WPR07/6/.25)
Standards: to DIN 3962, 3963, 3967 Grade 12. Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. White POM CPOM Mod 0.7 Rack 6x6.7x250mm (WPR07/6/.25) Part No. 7700-103 Code WPR07/6/.25 Pitch module 0.7 Width B 6 Overall height A 6.7 Height to pitch line hp 6 Length L 250 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£4.16
-
Hostaform Hostaform MOD 1 Rack 9x9x250mm (WPR10/9/.25)
Standards: to DIN 3962, 3963, 3967 Grade 12. Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. White POM CPOM Mod 1 Rack 9x9x250mm (WPR10/9/.25) Part No. 7700-104 Code WPR10/9/.25 Pitch module 1 Width B 9 Overall height A 9 Height to pitch line hp 8 Length L 250 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£6.03
-
Hostaform Hostaform MOD 1.25 Rack 10x11x250mm (WPR12.5/10/.25)
Standards: to DIN 3962, 3963, 3967 Grade 12. Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. White POM CPOM Mod 1.25 Rack 10x11x250mm (WPR12.5/10/.25) Part No. 7700-105 Code WPR12.5/10/.25 Pitch module 1.25 Width B 10 Overall height A 11 Height to pitch line hp 9.75 Length L 250 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£7.17
-
Hostaform Hostaform MOD 1.5 Rack 12x12x250mm (WPR15/12/.25)
Standards: to DIN 3962, 3963, 3967 Grade 12. Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. White POM CPOM Mod 1.5 Rack 12x12x250mm (WPR15/12/.25) Part No. 7700-106 Code WPR15/12/.25 Pitch module 1.5 Width B 12 Overall height A 12 Height to pitch line hp 10.5 Length L 250 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£8.75
-
Hostaform Hostaform MOD 2 Rack 15.4x11x250mm (WPR20/15/.25)
Standards: to DIN 3962, 3963, 3967 Grade 12. Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. White POM CPOM Mod 2 Rack 15.4x11x250mm (WPR20/15/.25) Part No. 7700-107 Code WPR20/15/.25 Pitch module 2 Width B 15.4 Overall height A 11 Height to pitch line hp 9 Length L 250 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£14.36
-
Hostaform Hostaform MOD 3 Rack 19.4x11x250mm (WPR30/19/.25)
Standards: to DIN 3962, 3963, 3967 Grade 12. Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. White POM CPOM Mod 3 Rack 19.4x11x250mm (WPR30/19/.25) Part No. 7700-108 Code WPR30/19/.25 Pitch module 3 Width B 19.4 Overall height A 15 Height to pitch line hp 12 Length L 250 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£18.55
-
Delrin Acetal/Delrin MOD 0.8 6x12x400mm Plastic Rack (DR08/6/.4)
Standards: to DIN 867, 3962, 3963, Grade/Quality 9 or equivalent. Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. Acetal/DELRIN racks teeth machinedAcetal/Delrin Mod 0.8 6x12x400mm Plastic Rack (DR08/6/.4) Part No. 7700-109 Code DR08/6/.4 Pitch module 0.8 Width B 6 Overall height A 12 Height to pitch line hp 11.2 Length L 400 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£42.59
-
Delrin Acetal/Delrin MOD 1 10x10x500mm Plastic Rack (DR10/10/.5)
Standards: to DIN 867, 3962, 3963, Grade/Quality 9 or equivalent. Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. Acetal/DELRIN racks teeth machinedAcetal/Delrin Mod 1 10x10x500mm Plastic Rack (DR10/10/.5) Part No. 7700-110 Code DR10/10/.5 Pitch module 1 Width B 10 Overall height A 10 Height to pitch line hp 9 Length L 500 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£38.07
-
Delrin Acetal/Delrin MOD 1 10x10x1000mm Plastic Rack (DR10/10/1)
Standards: to DIN 867, 3962, 3963, Grade/Quality 9 or equivalent. Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. Acetal/DELRIN racks teeth machinedAcetal/Delrin Mod 1 10x10x1000mm Plastic Rack (DR10/10/1) Part No. 7700-111 Code DR10/10/1 Pitch module 1 Width B 10 Overall height A 10 Height to pitch line hp 9 Length L 1000 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£72.56
-
Delrin Acetal/Delrin MOD 1 15x15x500mm Plastic Rack (DR10/15/.5)
Standards: to DIN 867, 3962, 3963, Grade/Quality 9 or equivalent. Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. Acetal/DELRIN racks teeth machinedAcetal/Delrin Mod 1 15x15x500mm Plastic Rack (DR10/15/.5) Part No. 7700-112 Code DR10/15/.5 Pitch module 1 Width B 15 Overall height A 15 Height to pitch line hp 14 Length L 500 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£44.81
-
Delrin Acetal/Delrin MOD 1 15x15x1000mm Plastic Rack (DR10/15/1)
Standards: to DIN 867, 3962, 3963, Grade/Quality 9 or equivalent. Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. Acetal/DELRIN racks teeth machinedAcetal/Delrin Mod 1 15x15x1000mm Plastic Rack (DR10/15/1) Part No. 7700-113 Code DR10/15/1 Pitch module 1 Width B 15 Overall height A 15 Height to pitch line hp 14 Length L 1000 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£85.41
-
Delrin Acetal/Delrin MOD 1 8x15x400mm Plastic Rack (DR10/8/.4)
Standards: to DIN 867, 3962, 3963, Grade/Quality 9 or equivalent. Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. Acetal/DELRIN racks teeth machinedAcetal/Delrin Mod 1 8x15x400mm Plastic Rack (DR10/8/.4) Part No. 7700-114 Code DR10/8/.4 Pitch module 1 Width B 8 Overall height A 15 Height to pitch line hp 14 Length L 400 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£47.07
-
Delrin Acetal/Delrin MOD 1 8x15x1000mm Plastic Rack (DR10/8/1)
Standards: to DIN 867, 3962, 3963, Grade/Quality 9 or equivalent. Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. Acetal/DELRIN racks teeth machinedAcetal/Delrin Mod 1 8x15x1000mm Plastic Rack (DR10/8/1) Part No. 7700-115 Code DR10/8/1 Pitch module 1 Width B 8 Overall height A 15 Height to pitch line hp 14 Length L 1000 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£91.38
-
Delrin Acetal/Delrin MOD 1.25 10x10x500mm Plastic Rack (DR12.5/10/.5)
Standards: to DIN 867, 3962, 3963, Grade/Quality 9 or equivalent. Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. Acetal/DELRIN racks teeth machinedAcetal/Delrin Mod 1.25 10x10x500mm Plastic Rack (DR12.5/10/.5) Part No. 7700-116 Code DR12.5/10/.5 Pitch module 1.25 Width B 10 Overall height A 10 Height to pitch line hp 8.75 Length L 500 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£46.64
-
Delrin Acetal/Delrin MOD 1.5 12x18x400mm Plastic Rack (DR15/12/.4)
Standards: to DIN 867, 3962, 3963, Grade/Quality 9 or equivalent. Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. Acetal/DELRIN racks teeth machinedAcetal/Delrin Mod 1.5 12x18x400mm Plastic Rack (DR15/12/.4) Part No. 7700-117 Code DR15/12/.4 Pitch module 1.5 Width B 12 Overall height A 18 Height to pitch line hp 16 Length L 400 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£48.89
-
Delrin Acetal/Delrin MOD 1.5 12x18x1000mm Plastic Rack (DR15/12/1)
Standards: to DIN 867, 3962, 3963, Grade/Quality 9 or equivalent. Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. Acetal/DELRIN racks teeth machinedAcetal/Delrin Mod 1.5 12x18x1000mm Plastic Rack (DR15/12/1) Part No. 7700-118 Code DR15/12/1 Pitch module 1.5 Width B 12 Overall height A 18 Height to pitch line hp 16 Length L 1000 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£94.07
-
Delrin Acetal/Delrin MOD 1.5 17x17x500mm Plastic Rack (DR15/17/.5)
Standards: to DIN 867, 3962, 3963, Grade/Quality 9 or equivalent. Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. Acetal/DELRIN racks teeth machinedAcetal/Delrin Mod 1.5 17x17x500mm Plastic Rack (DR15/17/.5) Part No. 7700-119 Code DR15/17/.5 Pitch module 1.5 Width B 17 Overall height A 17 Height to pitch line hp 15.5 Length L 500 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£48.40
-
Delrin Acetal/Delrin MOD 1.5 17x17x1000mm Plastic Rack (DR15/17/1)
Standards: to DIN 867, 3962, 3963, Grade/Quality 9 or equivalent. Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. Acetal/DELRIN racks teeth machinedAcetal/Delrin Mod 1.5 17x17x1000mm Plastic Rack (DR15/17/1) Part No. 7700-120 Code DR15/17/1 Pitch module 1.5 Width B 17 Overall height A 17 Height to pitch line hp 15.5 Length L 1000 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£92.19
-
30% Glass Filled Nylon 6 Rack MOD 0.5, 8x8x250mm
Module 1.5 to 4.0 have a steel core. All dimensions in mm. 30% Glass filled Nylon 6Nylon 6 Mod 0.5 8x8x250mm Plastic Rack (PR05/08/.25T) Part No. 7700-121 Code PR05/8/.25 Pitch module 1 Type S Width B 8 Height A 8 Height to pitch line hp 7.5 Length L 250 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£10.92
-
Nylon 6 MOD 1 15x13.1x150mm Plastic Rack (PR10/15/.15T)
Module 1.5 to 4.0 have a steel core. All dimensions in mm. 30% Glass filled Nylon 6Nylon 6 Mod 1 15x13.1x150mm Plastic Rack (PR10/15/.15T) Part No. 7700-122 Code PR10/15/.15T Pitch module 1 Type *T* Width B 15 Height A 13.16 Height to pitch line hp 12.2 Length L 150 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£12.22
-
Nylon 6 MOD 1 15x15x250mm Plastic Rack (PR10/15/.25C)
Module 1.5 to 4.0 have a steel core. All dimensions in mm. 30% Glass filled Nylon 6Nylon 6 Mod 1 15x15x250mm Plastic Rack (PR10/15/.25C) Part No. 7700-123 Code PR10/15/.25C Pitch module 1 Type S Width B 15 Height A 15 Height to pitch line hp 14 Length L 250 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£14.00
-
Nylon 6 MOD 1 15x13.1x250mm Plastic Rack (PR10/15/.25T)
Module 1.5 to 4.0 have a steel core. All dimensions in mm. 30% Glass filled Nylon 6Nylon 6 Mod 1 15x13.1x250mm Plastic Rack (PR10/15/.25T) Part No. 7700-124 Code PR10/15/.25T Pitch module 1 Type *T* Width B 15 Height A 13.16 Height to pitch line hp 12.2 Length L 250 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£13.68
You have seen 25 out of 156 products
