L Pilot Bore Timing Pulleys
-
Pulley 10L050F, With Pilot Bore (P10L050F)
Timing Pulleys L050 (0.375" / 9.525mm pitch) for 12.7mm (1/2") wide belt. Pilot bore, manufactured in steel or Cast Iron with steel flanges.Pulley 10L050F, With Pilot Bore (P10L050F) Part No. 7801-001 Material P10L050F Code P10L050F Type 1F No. Teeth 10 Dp 30 De 30 Df 37 Dm 20 F 19 L 28 Bore(d) 8 No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£3.22
-
Pulley 10L075F, With Pilot Bore (P10L075F)
Timing Pulleys L075 (0.375" / 9.525mm pitch) for 19.05mm (3/4") wide belt. Pilot bore, manufactured in steel or Cast Iron with steel flanges.Pulley 10L075F, With Pilot Bore (P10L075F) Part No. 7801-002 Code P10L075F Material Steel Type 1F No. Teeth 10 Dp 30 De 30 Df 37 Dm 20 F 25.4 L 38 Bore 8 No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£3.74
-
Pulley 10L100F, With Pilot Bore (P10L100F)
Timing Pulleys L100 (0.375" / 9.525mm pitch) for 25.4mm (1") wide belt. Pilot bore, manufactured in steel or Cast Iron with steel flanges.Pulley 10L100F, With Pilot Bore (P10L100F) Part No. 7801-003 Code P10L100F Material Steel Type 1F No. Teeth 10 Dp 30 De 30 Df 37 Dm 20 F 31.8 L 45 Bore 8 No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£4.19
-
Pulley 12L050F, With Pilot Bore (P12L050F)
Timing Pulleys L050 (0.375" / 9.525mm pitch) for 12.7mm (1/2") wide belt. Pilot bore, manufactured in steel or Cast Iron with steel flanges.Pulley 12L050F, With Pilot Bore (P12L050F) Part No. 7801-004 Material P12L050F Code P12L050F Type 1F No. Teeth 12 Dp 36 De 36 Df 43 Dm 24 F 19 L 30 Bore(d) 8 No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£3.82
-
Pulley 12L075F, With Pilot Bore (P12L075F)
Timing Pulleys L075 (0.375" / 9.525mm pitch) for 19.05mm (3/4") wide belt. Pilot bore, manufactured in steel or Cast Iron with steel flanges.Pulley 12L075F, With Pilot Bore (P12L075F) Part No. 7801-005 Code P12L075F Material Steel Type 1F No. Teeth 12 Dp 36 De 33 Df 43 Dm 24 F 25.4 L 38 Bore 8 No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£4.39
-
Pulley 12L100F, With Pilot Bore (P12L100F)
Timing Pulleys L100 (0.375" / 9.525mm pitch) for 25.4mm (1") wide belt. Pilot bore, manufactured in steel or Cast Iron with steel flanges.Pulley 12L100F, With Pilot Bore (P12L100F) Part No. 7801-006 Code P12L100F Material Steel Type 1F No. Teeth 12 Dp 36 De 36 Df 43 Dm 24 F 31.8 L 45 Bore 8 No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£4.91
-
Pulley 13L050F, With Pilot Bore (P13L050F)
Timing Pulleys L050 (0.375" / 9.525mm pitch) for 12.7mm (1/2") wide belt. Pilot bore, manufactured in steel or Cast Iron with steel flanges.Pulley 13L050F, With Pilot Bore (P13L050F) Part No. 7801-007 Material P13L050F Code P13L050F Type 1F No. Teeth 13 Dp 39 De 39 Df 44 Dm 28 F 19 L 30 Bore(d) 8 No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£4.19
-
Pulley 13L075F, With Pilot Bore (P13L075F)
Timing Pulleys L075 (0.375" / 9.525mm pitch) for 19.05mm (3/4") wide belt. Pilot bore, manufactured in steel or Cast Iron with steel flanges.Pulley 13L075F, With Pilot Bore (P13L075F) Part No. 7801-008 Code P13L075F Material Steel Type 1F No. Teeth 13 Dp 39 De 39 Df 44 Dm 28 F 25.4 L 38 Bore 8 No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£4.91
-
Pulley 13L100F, With Pilot Bore (P13L100F)
Timing Pulleys L100 (0.375" / 9.525mm pitch) for 25.4mm (1") wide belt. Pilot bore, manufactured in steel or Cast Iron with steel flanges.Pulley 13L100F, With Pilot Bore (P13L100F) Part No. 7801-009 Code P13L100F Material Steel Type 1F No. Teeth 13 Dp 39 De 39 Df 44 Dm 28 F 31.8 L 45 Bore 8 No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£5.36
-
Pulley 14L050F, With Pilot Bore (P14L050F)
Timing Pulleys L050 (0.375" / 9.525mm pitch) for 12.7mm (1/2") wide belt. Pilot bore, manufactured in steel or Cast Iron with steel flanges.Pulley 14L050F, With Pilot Bore (P14L050F) Part No. 7801-010 Material P14L050F Code P14L050F Type 1F No. Teeth 14 Dp 42 De 42 Df 48 Dm 28 F 19 L 30 Bore(d) 8 No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£4.52
-
Pulley 14L075F, With Pilot Bore (P14L075F)
Timing Pulleys L075 (0.375" / 9.525mm pitch) for 19.05mm (3/4") wide belt. Pilot bore, manufactured in steel or Cast Iron with steel flanges.Pulley 14L075F, With Pilot Bore (P14L075F) Part No. 7801-011 Code P14L075F Material Steel Type 1F No. Teeth 14 Dp 42 De 42 Df 48 Dm 28 F 25.4 L 38 Bore 11 No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£5.17
-
Pulley 14L100F, With Pilot Bore (P14L100F)
Timing Pulleys L100 (0.375" / 9.525mm pitch) for 25.4mm (1") wide belt. Pilot bore, manufactured in steel or Cast Iron with steel flanges.Pulley 14L100F, With Pilot Bore (P14L100F) Part No. 7801-012 Code P14L100F Material Steel Type 1F No. Teeth 14 Dp 42 De 42 Df 48 Dm 28 F 31.8 L 45 Bore 11 No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£5.75
-
Pulley 15L050F, With Pilot Bore (P15L050F)
Timing Pulleys L050 (0.375" / 9.525mm pitch) for 12.7mm (1/2") wide belt. Pilot bore, manufactured in steel or Cast Iron with steel flanges.Pulley 15L050F, With Pilot Bore (P15L050F) Part No. 7801-013 Material P15L050F Code P15L050F Type 1F No. Teeth 15 Dp 45 De 45 Df 51 Dm 34 F 19 L 30 Bore(d) 8 No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£5.04
-
Pulley 15L075F, With Pilot Bore (P15L075F)
Timing Pulleys L075 (0.375" / 9.525mm pitch) for 19.05mm (3/4") wide belt. Pilot bore, manufactured in steel or Cast Iron with steel flanges.Pulley 15L075F, With Pilot Bore (P15L075F) Part No. 7801-014 Code P15L075F Material Steel Type 1F No. Teeth 15 Dp 45 De 45 Df 51 Dm 34 F 25.4 L 38 Bore 11 No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£5.69
-
Pulley 15L100F, With Pilot Bore (P15L100F)
Timing Pulleys L100 (0.375" / 9.525mm pitch) for 25.4mm (1") wide belt. Pilot bore, manufactured in steel or Cast Iron with steel flanges.Pulley 15L100F, With Pilot Bore (P15L100F) Part No. 7801-015 Code P15L100F Material Steel Type 1F No. Teeth 15 Dp 45 De 45 Df 51 Dm 34 F 31.8 L 45 Bore 11 No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£6.32
-
Pulley 16L050F, With Pilot Bore (P16L050F)
Timing Pulleys L050 (0.375" / 9.525mm pitch) for 12.7mm (1/2") wide belt. Pilot bore, manufactured in steel or Cast Iron with steel flanges.Pulley 16L050F, With Pilot Bore (P16L050F) Part No. 7801-016 Material P16L050F Code P16L050F Type 1F No. Teeth 16 Dp 49 De 48 Df 54 Dm 36 F 19 L 32 Bore(d) 8 No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£5.28
-
Pulley 16L075F, With Pilot Bore (P16L075F)
Timing Pulleys L075 (0.375" / 9.525mm pitch) for 19.05mm (3/4") wide belt. Pilot bore, manufactured in steel or Cast Iron with steel flanges.Pulley 16L075F, With Pilot Bore (P16L075F) Part No. 7801-017 Code P16L075F Material Steel Type 1F No. Teeth 16 Dp 49 De 48 Df 54 Dm 36 F 25.4 L 38 Bore 11 No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£5.88
-
Pulley 16L100F, With Pilot Bore (P16L100F)
Timing Pulleys L100 (0.375" / 9.525mm pitch) for 25.4mm (1") wide belt. Pilot bore, manufactured in steel or Cast Iron with steel flanges.Pulley 16L100F, With Pilot Bore (P16L100F) Part No. 7801-018 Code P16L100F Material Steel Type 1F No. Teeth 16 Dp 49 De 48 Df 54 Dm 36 F 31.8 L 45 Bore 11 No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£6.45
-
Pulley 17L050F, With Pilot Bore (P17L050F)
Timing Pulleys L050 (0.375" / 9.525mm pitch) for 12.7mm (1/2") wide belt. Pilot bore, manufactured in steel or Cast Iron with steel flanges.Pulley 17L050F, With Pilot Bore (P17L050F) Part No. 7801-019 Material P17L050F Code P17L050F Type 1F No. Teeth 17 Dp 52 De 51 Df 57 Dm 36 F 19 L 32 Bore(d) 10 No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£5.75
-
Pulley 17L075F, With Pilot Bore (P17L075F)
Timing Pulleys L075 (0.375" / 9.525mm pitch) for 19.05mm (3/4") wide belt. Pilot bore, manufactured in steel or Cast Iron with steel flanges.Pulley 17L075F, With Pilot Bore (P17L075F) Part No. 7801-020 Code P17L075F Material Steel Type 1F No. Teeth 17 Dp 52 De 51 Df 57 Dm 36 F 25.4 L 38 Bore 11 No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£6.45
-
Pulley 17L100F, With Pilot Bore (P17L100F)
Timing Pulleys L100 (0.375" / 9.525mm pitch) for 25.4mm (1") wide belt. Pilot bore, manufactured in steel or Cast Iron with steel flanges.Pulley 17L100F, With Pilot Bore (P17L100F) Part No. 7801-021 Code P17L100F Material Steel Type 1F No. Teeth 17 Dp 52 De 51 Df 57 Dm 36 F 31.8 L 45 Bore 11 No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£7.05
-
Pulley 18L050F, With Pilot Bore (P18L050F)
Timing Pulleys L050 (0.375" / 9.525mm pitch) for 12.7mm (1/2") wide belt. Pilot bore, manufactured in steel or Cast Iron with steel flanges.Pulley 18L050F, With Pilot Bore (P18L050F) Part No. 7801-022 Material P18L050F Code P18L050F Type 1F No. Teeth 18 Dp 55 De 54 Df 60 Dm 40 F 19 L 32 Bore(d) 10 No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£6.40
-
Pulley 18L075F, With Pilot Bore (P18L075F)
Timing Pulleys L075 (0.375" / 9.525mm pitch) for 19.05mm (3/4") wide belt. Pilot bore, manufactured in steel or Cast Iron with steel flanges.Pulley 18L075F, With Pilot Bore (P18L075F) Part No. 7801-023 Code P18L075F Material Steel Type 1F No. Teeth 18 Dp 55 De 54 Df 60 Dm 40 F 25.4 L 38 Bore 11 No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£7.10
-
Pulley 18L100F, With Pilot Bore (P18L100F)
Timing Pulleys L100 (0.375" / 9.525mm pitch) for 25.4mm (1") wide belt. Pilot bore, manufactured in steel or Cast Iron with steel flanges.Pulley 18L100F, With Pilot Bore (P18L100F) Part No. 7801-024 Code P18L100F Material Steel Type 1F No. Teeth 18 Dp 55 De 54 Df 60 Dm 40 F 31.8 L 45 Bore 11 No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£7.88
-
Pulley 19L050F, With Pilot Bore (P19L050F)
Timing Pulleys L050 (0.375" / 9.525mm pitch) for 12.7mm (1/2") wide belt. Pilot bore, manufactured in steel or Cast Iron with steel flanges.Pulley 19L050F, With Pilot Bore (P19L050F) Part No. 7801-025 Material P19L050F Code P19L050F Type 1F No. Teeth 19 Dp 58 De 57 Df 64 Dm 40 F 19 L 32 Bore(d) 10 No. Flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£6.66
You have seen 25 out of 93 products
