Idler Sprockets
-
Idler Sprocket 8mm 23 Tooth
An 05B 8mm idler sprocket, 23 tooth with a 16mm bore. Used with long chain lengths or for chain tensioning.* Complete with fully shielded and greased for life ball bearings. * Also known as Jockey Sprockets
£6.95
-
Idler Sprocket 3/8" 21 Tooth
An 06B 3/8" idler sprocket, 21 tooth with a 16mm bore. Used with long chain lengths or for chain tensioning.* Complete with fully shielded and greased for life ball bearings. * Also known as Jockey Sprockets
£7.50
-
6B 21T Idler Sprocket Budget Bearing (I3SR21B)
British Standard sprockets with integral bearings (budget or INA) for use as an idler.6B 21T Idler Sprocket Budget Bearing (I3SR21B) Part No. 7830-104 Code I3SR21B No. teeth 21 Pitch de dp A D1* F B H Bearing Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£8.59
-
INA 6B 21T Idler Sprocket INA Bearing (I3SR21I)
British Standard sprockets with integral bearings (INA) for use as an idler.6B 21T Idler Sprocket INA Bearing (I3SR21I) Part No. 7830-204 Code I3SR21I No. teeth 21 Pitch 3/8? x 7/32? de 68 dp 63.9 A 5.3 D1* 16 F 40 B 12 H 18.3 Bearing INA Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£27.56
-
6B 22T Idler Sprocket Budget Bearing (I3SR22B)
British Standard sprockets with integral bearings (budget) for use as an idler.6B 22T Idler Sprocket Budget Bearing (I3SR22B) Part No. 7830-105 Code I3SR22B No. teeth 22 Pitch 3/8? x 7/32? de 71 dp 66.93 A 5.3 D1* 16 F 40 B 12 H 18.3 Bearing Budget Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£8.04
-
Idler Sprocket 081 1/2" 18 Tooth
An 081 1/2" idler sprocket, 18 tooth with a 16mm bore. Used with long chain lengths or for chain tensioning. Note for use only with our 081 chain which is narrower than our 08B chain.* Complete with fully shielded and greased for life ball bearings. * Also known as Jockey Sprockets
£7.39
-
081 18T Idler Sprocket Budget Bearing (I1SR18B)
British Standard sprockets with integral bearings (budget or INA) for use as an idler.1SR 18T Idler Sprocket Budget Bearing (I1SR18B) Part No. 7830-102 Code I1SR18B No. teeth 18 Pitch de dp A D1* F B H Bearing Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£8.51
-
INA 081 18T Idler Sprocket INA Bearing (I1SR18I)
British Standard sprockets with integral bearings (INA) for use as an idler.1SR 18T Idler Sprocket INA Bearing (I1SR18I) Part No. 7830-202 Code I1SR18I No. teeth 18 Pitch 1/2? x 1/8? de 78.9 dp 73.14 A 3 D1* 16 F 40 B 12 H 18.3 Bearing INA Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£31.94
-
083 18T Idler Sprocket Budget Bearing (I2SR18B)
British Standard sprockets with integral bearings (budget) for use as an idler.2SR 18T Idler Sprocket Budget Bearing (I2SR18B) Part No. 7830-103 Code I2SR18B No. teeth 18 Pitch 1/2? x 3/16? de 78.9 dp 73.13 A 4.5 D1* 16 F 40 B 12 H 18.3 Bearing Budget Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£8.51
-
INA 083 18T Idler Sprocket INA Bearing (I2SR18I)
British Standard sprockets with integral bearings (INA) for use as an idler.2SR 18T Idler Sprocket INA Bearing (I2SR18I) Part No. 7830-203 Code I2SR18I No. teeth 18 Pitch 1/2? x 3/16? de 78.9 dp 73.13 A 4.5 D1* 16 F 40 B 12 H 18.3 Bearing INA Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£31.94
-
Idler Sprocket 08B 1/2" 16 Tooth
An 08B 1/2" idler sprocket, 16 tooth with a 16mm bore. Used with long chain lengths or for chain tensioning.* Complete with fully shielded and greased for life ball bearings. * Also known as Jockey Sprockets
£8.13
-
8B 16T Idler Sprocket Budget Bearing (I4SR16B)
British Standard sprockets with integral bearings (budget or INA) for use as an idler.8B 16T Idler Sprocket Budget Bearing (I4SR16B) Part No. 7830-106 Code I4SR16B No. teeth 16 Pitch de dp A D1* F B H Bearing Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£6.58
-
INA 8B 16T Idler Sprocket INA Bearing (I4SR16I)
British Standard sprockets with integral bearings (INA) for use as an idler.8B 16T Idler Sprocket INA Bearing (I4SR16I) Part No. 7830-205 Code I4SR16I No. teeth 16 Pitch 1/2? x 5/16? de 69.5 dp 65.1 A 7.2 D1* 16 F 40 B 12 H 18.3 Bearing INA Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£28.69
-
8B 18T Idler Sprocket Budget Bearing (I4SR18B)
British Standard sprockets with integral bearings (budget or INA) for use as an idler.8B 18T Idler Sprocket Budget Bearing (I4SR18B) Part No. 7830-107 Code I4SR18B No. teeth 18 Pitch de dp A D1* F B H Bearing Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£6.91
-
INA 8B 18T Idler Sprocket INA Bearing (I4SR18I)
British Standard sprockets with integral bearings (INA) for use as an idler.8B 18T Idler Sprocket INA Bearing (I4SR18I) Part No. 7830-206 Code I4SR18I No. teeth 18 Pitch 1/2? x 5/16? de 77.8 dp 73.14 A 7.2 D1* 16 F 40 B 12 H 18.3 Bearing INA Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£29.26
-
10B 14T Idler Sprocket Budget Bearing (I5SR14B)
British Standard sprockets with integral bearings (budget) for use as an idler.10B 14T Idler Sprocket Budget Bearing (I5SR14B) Part No. 7830-108 Code I5SR14B No. teeth 14 Pitch 5/8? x 3/8? de 78 dp 71.34 A 9.1 D1* 16 F 40 B 12 H 18.3 Bearing Budget Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£7.27
-
INA 10B 14T Idler Sprocket INA Bearing (I5SR14I)
British Standard sprockets with integral bearings (INA) for use as an idler.10B 14T Idler Sprocket INA Bearing (I5SR14I) Part No. 7830-207 Code I5SR14I No. teeth 14 Pitch 5/8? x 3/8? de 78 dp 71.34 A 9.1 D1* 16 F 40 B 12 H 18.3 Bearing INA Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£30.61
-
10B 15T Idler Sprocket Budget Bearing (I5SR15B)
British Standard sprockets with integral bearings (budget) for use as an idler.10B 15T Idler Sprocket Budget Bearing (I5SR15B) Part No. 7830-109 Code I5SR15B No. teeth 15 Pitch 5/8? x 3/8? de 83 dp 76.36 A 9.1 D1* 16 F 40 B 12 H 18.3 Bearing Budget Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£10.51
-
INA 10B 15T Idler Sprocket INA Bearing (I5SR15I)
British Standard sprockets with integral bearings (INA) for use as an idler.10B 15T Idler Sprocket INA Bearing (I5SR15I) Part No. 7830-208 Code I5SR15I No. teeth 15 Pitch 5/8? x 3/8? de 83 dp 76.36 A 9.1 D1* 16 F 40 B 12 H 18.3 Bearing INA Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£32.89
-
10B 17T Idler Sprocket Budget Bearing (I5SR17B)
British Standard sprockets with integral bearings (budget) for use as an idler.10B 17T Idler Sprocket Budget Bearing (I5SR17B) Part No. 7830-110 Code I5SR17B No. teeth 17 Pitch 5/8? x 3/8? de 93 dp 86.39 A 9.1 D1* 16 F 40 B 12 H 18.3 Bearing Budget Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£8.52
-
INA 10B 17T Idler Sprocket INA Bearing (I5SR17I)
British Standard sprockets with integral bearings (INA) for use as an idler.10B 17T Idler Sprocket INA Bearing (I5SR17I) Part No. 7830-209 Code I5SR17I No. teeth 17 Pitch 5/8? x 3/8? de 93 dp 86.39 A 9.1 D1* 16 F 40 B 12 H 18.3 Bearing INA Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£31.32
-
12B 13T Idler Sprocket Budget Bearing (I6SR13B)
British Standard sprockets with integral bearings (budget) for use as an idler.12B 13T Idler Sprocket Budget Bearing (I6SR13B) Part No. 7830-111 Code I6SR13B No. teeth 13 Pitch 3/4? x 7/16? de 87.5 dp 79.59 A 11.1 D1* 16 F 40 B 12 H 18.3 Bearing Budget Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£11.38
-
INA 12B 13T Idler Sprocket INA Bearing (I6SR13I)
British Standard sprockets with integral bearings (INA) for use as an idler.12B 13T Idler Sprocket INA Bearing (I6SR13I) Part No. 7830-210 Code I6SR13I No. teeth 13 Pitch 3/4? x 7/16? de 87.5 dp 79.59 A 11.1 D1* 16 F 40 B 12 H 18.3 Bearing INA Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£32.61
-
12B 15T Idler Sprocket Budget Bearing (I6SR15B)
British Standard sprockets with integral bearings (budget) for use as an idler.12B 15T Idler Sprocket Budget Bearing (I6SR15B) Part No. 7830-112 Code I6SR15B No. teeth 15 Pitch 3/4? x 7/16? de 99.8 dp 91.63 A 11.1 D1* 16 F 40 B 12 H 18.3 Bearing Budget Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£9.24
-
INA 12B 15T Idler Sprocket INA Bearing (I6SR15I)
British Standard sprockets with integral bearings (INA) for use as an idler.12B 15T Idler Sprocket INA Bearing (I6SR15I) Part No. 7830-211 Code I6SR15I No. teeth 15 Pitch 3/4? x 7/16? de 99.8 dp 91.63 A 11.1 D1* 16 F 40 B 12 H 18.3 Bearing INA Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£33.18
You have seen 25 out of 29 products
