Drivelock Bushes
-
Drivelock 11 100x145mm (DL11/100)
Drivelock 11 Bushes are self centering, offer very high torques 784 to 419860 Nm and are available in bores from 25 to 300mmDrivelock 11 100x145mm (DL11/100) Part No. 7930-001 Code. DL11/100 d (h8) (mm) 100 D (mm) 145 M (mm) M12 L (mm) 112 B (mm) 100 Ts Nm 145 T Nm 25791 F kN 516 p N/mm2 104 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£120.29
-
Drivelock 11 110x155mm (DL11/110)
Drivelock 11 Bushes are self centering, offer very high torques 784 to 419860 Nm and are available in bores from 25 to 300mmDrivelock 11 110x155mm (DL11/110) Part No. 7930-002 Code. DL11/110 d (h8) (mm) 110 D (mm) 155 M (mm) M12 L (mm) 112 B (mm) 100 Ts Nm 145 T Nm 31184 F kN 564 p N/mm2 107 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£137.17
-
Drivelock 11 120x165mm (DL11/120)
Drivelock 11 Bushes are self centering, offer very high torques 784 to 419860 Nm and are available in bores from 25 to 300mmDrivelock 11 120x165mm (DL11/120) Part No. 7930-003 Code. DL11/120 d (h8) (mm) 120 D (mm) 165 M (mm) M12 L (mm) 112 B (mm) 100 Ts Nm 145 T Nm 39618 F kN 657 p N/mm2 117 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£147.29
-
Drivelock 11 130x180mm (DL11/130)
Drivelock 11 Bushes are self centering, offer very high torques 784 to 419860 Nm and are available in bores from 25 to 300mmDrivelock 11 130x180mm (DL11/130) Part No. 7930-004 Code. DL11/130 d (h8) (mm) 130 D (mm) 180 M (mm) M14 L (mm) 130 B (mm) 116 Ts Nm 230 T Nm 50503 F kN 774 p N/mm2 109 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£185.03
-
Drivelock 11 140x190mm (DL11/140)
Drivelock 11 Bushes are self centering, offer very high torques 784 to 419860 Nm and are available in bores from 25 to 300mmDrivelock 11 140x190mm (DL11/140) Part No. 7930-005 Code. DL11/140 d (h8) (mm) 140 D (mm) 190 M (mm) M14 L (mm) 130 B (mm) 116 Ts Nm 230 T Nm 63470 F kN 902 p N/mm2 121 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£240.97
-
Drivelock 11 150x200mm (DL11/150)
Drivelock 11 Bushes are self centering, offer very high torques 784 to 419860 Nm and are available in bores from 25 to 300mmDrivelock 11 150x200mm (DL11/150) Part No. 7930-006 Code. DL11/150 d (h8) (mm) 150 D (mm) 200 M (mm) M14 L (mm) 130 B (mm) 116 Ts Nm 230 T Nm 72790 F kN 967 p N/mm2 124 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£261.18
-
Drivelock 11 160x210mm (DL11/160)
Drivelock 11 Bushes are self centering, offer very high torques 784 to 419860 Nm and are available in bores from 25 to 300mmDrivelock 11 160x210mm (DL11/160) Part No. 7930-007 Code. DL11/160 d (h8) (mm) 160 D (mm) 210 M (mm) M14 L (mm) 130 B (mm) 116 Ts Nm 230 T Nm 82890 F kN 1030 p N/mm2 125 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£292.66
-
Drivelock 11 170x225mm (DL11/170)
Drivelock 11 Bushes are self centering, offer very high torques 784 to 419860 Nm and are available in bores from 25 to 300mmDrivelock 11 170x225mm (DL11/170) Part No. 7930-008 Code. DL11/170 d (h8) (mm) 170 D (mm) 225 M (mm) M16 L (mm) 164 B (mm) 148 Ts Nm 355 T Nm 106000 F kN 1255 p N/mm2 110 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£415.19
-
Drivelock 11 180x235mm (DL11/180)
Drivelock 11 Bushes are self centering, offer very high torques 784 to 419860 Nm and are available in bores from 25 to 300mmDrivelock 11 180x235mm (DL11/180) Part No. 7930-009 Code. DL11/180 d (h8) (mm) 180 D (mm) 235 M (mm) M16 L (mm) 164 B (mm) 148 Ts Nm 355 T Nm 120900 F kN 1343 p N/mm2 112 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£431.30
-
Drivelock 11 190x250mm (DL11/190)
Drivelock 11 Bushes are self centering, offer very high torques 784 to 419860 Nm and are available in bores from 25 to 300mmDrivelock 11 190x250mm (DL11/190) Part No. 7930-010 Code. DL11/190 d (h8) (mm) 190 D (mm) 250 M (mm) M16 L (mm) 164 B (mm) 148 Ts Nm 355 T Nm 131250 F kN 1432 p N/mm2 113 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£489.38
-
Drivelock 11 200x260mm (DL11/200)
Drivelock 11 Bushes are self centering, offer very high torques 784 to 419860 Nm and are available in bores from 25 to 300mmDrivelock 11 200x260mm (DL11/200) Part No. 7930-011 Code. DL11/200 d (h8) (mm) 200 D (mm) 260 M (mm) M16 L (mm) 164 B (mm) 148 Ts Nm 355 T Nm 143220 F kN 1432 p N/mm2 110 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£517.47
-
Drivelock 11 220x285mm (DL11/220)
Drivelock 11 Bushes are self centering, offer very high torques 784 to 419860 Nm and are available in bores from 25 to 300mmDrivelock 11 220x285mm (DL11/220) Part No. 7930-012 Code. DL11/220 d (h8) (mm) 220 D (mm) 285 M (mm) M16 L (mm) 164 B (mm) 148 Ts Nm 355 T Nm 177560 F kN 1608 p N/mm2 112 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£629.60
-
Drivelock 11 25x55 mm (DL11/25)
Drivelock 11 Bushes are self centering, offer very high torques 784 to 419860 Nm and are available in bores from 25 to 300mmDrivelock 11 25x55 mm (DL11/25) Part No. 7930-013 Code. DL11/25 d (h8) (mm) 25 D (mm) 55 M (mm) M6 L (mm) 46 B (mm) 40 Ts Nm 17 T Nm 784 F kN 65 p N/mm2 99 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£26.59
-
Drivelock 11 28x55mm (DL11/28)
Drivelock 11 Bushes are self centering, offer very high torques 784 to 419860 Nm and are available in bores from 25 to 300mmDrivelock 11 28x55mm (DL11/28) Part No. 7930-014 Code. DL11/28 d (h8) (mm) 28 D (mm) 55 M (mm) M6 L (mm) 46 B (mm) 40 Ts Nm 17 T Nm 882 F kN 65 p N/mm2 99 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£26.61
-
Drivelock 11 30x55mm (DL11/30)
Drivelock 11 Bushes are self centering, offer very high torques 784 to 419860 Nm and are available in bores from 25 to 300mmDrivelock 11 30x55mm (DL11/30) Part No. 7930-015 Code. DL11/30 d (h8) (mm) 30 D (mm) 55 M (mm) M6 L (mm) 46 B (mm) 40 Ts Nm 17 T Nm 931 F kN 65 p N/mm2 99 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£26.63
-
Drivelock 11 35x60 mm (DL11/35)
Drivelock 11 Bushes are self centering, offer very high torques 784 to 419860 Nm and are available in bores from 25 to 300mmDrivelock 11 35x60 mm (DL11/35) Part No. 7930-016 Code. DL11/35 d (h8) (mm) 35 D (mm) 60 M (mm) M6 L (mm) 60 B (mm) 54 Ts Nm 17 T Nm 1274 F kN 72 p N/mm2 85 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£31.68
-
Drivelock 11 38x75mm (DL11/38)
Drivelock 11 Bushes are self centering, offer very high torques 784 to 419860 Nm and are available in bores from 25 to 300mmDrivelock 11 38x75mm (DL11/38) Part No. 7930-017 Code. DL11/38 d (h8) (mm) 38 D (mm) 75 M (mm) M8 L (mm) 62 B (mm) 54 Ts Nm 41 T Nm 2696 F kN 142 p N/mm2 113 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£39.36
-
Drivelock 11 40x75 mm (DL11/40)
Drivelock 11 Bushes are self centering, offer very high torques 784 to 419860 Nm and are available in bores from 25 to 300mmDrivelock 11 40x75 mm (DL11/40) Part No. 7930-018 Code. DL11/40 d (h8) (mm) 40 D (mm) 75 M (mm) M8 L (mm) 62 B (mm) 54 Ts Nm 41 T Nm 2843 F kN 142 p N/mm2 113 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£39.36
-
Drivelock 11 42x75mm (DL11/42)
Drivelock 11 Bushes are self centering, offer very high torques 784 to 419860 Nm and are available in bores from 25 to 300mmDrivelock 11 42x75mm (DL11/42) Part No. 7930-019 Code. DL11/42 d (h8) (mm) 42 D (mm) 75 M (mm) M8 L (mm) 62 B (mm) 54 Ts Nm 41 T Nm 2981 F kN 142 p N/mm2 113 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£43.84
-
Drivelock 11 45x75mm (DL11/45)
Drivelock 11 Bushes are self centering, offer very high torques 784 to 419860 Nm and are available in bores from 25 to 300mmDrivelock 11 45x75mm (DL11/45) Part No. 7930-020 Code. DL11/45 d (h8) (mm) 45 D (mm) 75 M (mm) M8 L (mm) 62 B (mm) 54 Ts Nm 41 T Nm 3196 F kN 142 p N/mm2 113 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£43.86
-
Drivelock 11 48x80mm (DL11/48)
Drivelock 11 Bushes are self centering, offer very high torques 784 to 419860 Nm and are available in bores from 25 to 300mmDrivelock 11 48x80mm (DL11/48) Part No. 7930-021 Code. DL11/48 d (h8) (mm) 48 D (mm) 80 M (mm) M8 L (mm) 62 B (mm) 54 Ts Nm 41 T Nm 3873 F kN 161 p N/mm2 96 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£48.37
-
Drivelock 11 50x80mm (DL11/50)
Drivelock 11 Bushes are self centering, offer very high torques 784 to 419860 Nm and are available in bores from 25 to 300mmDrivelock 11 50x80mm (DL11/50) Part No. 7930-022 Code. DL11/50 d (h8) (mm) 50 D (mm) 80 M (mm) M8 L (mm) 72 B (mm) 64 Ts Nm 41 T Nm 4069 F kN 161 p N/mm2 96 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£48.39
-
Drivelock 11 55x85 mm (DL11/55)
Drivelock 11 Bushes are self centering, offer very high torques 784 to 419860 Nm and are available in bores from 25 to 300mmDrivelock 11 55x85 mm (DL11/55) Part No. 7930-023 Code. DL11/55 d (h8) (mm) 55 D (mm) 85 M (mm) M8 L (mm) 72 B (mm) 64 Ts Nm 41 T Nm 5050 F kN 182 p N/mm2 101 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£52.87
-
Drivelock 11 60x90mm (DL11/60)
Drivelock 11 Bushes are self centering, offer very high torques 784 to 419860 Nm and are available in bores from 25 to 300mmDrivelock 11 60x90mm (DL11/60) Part No. 7930-024 Code. DL11/60 d (h8) (mm) 60 D (mm) 90 M (mm) M8 L (mm) 72 B (mm) 64 Ts Nm 41 T Nm 6080 F kN 203 p N/mm2 103 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£55.86
-
Drivelock 11 65x95mm (DL11/65)
Drivelock 11 Bushes are self centering, offer very high torques 784 to 419860 Nm and are available in bores from 25 to 300mmDrivelock 11 65x95mm (DL11/65) Part No. 7930-025 Code. DL11/65 d (h8) (mm) 65 D (mm) 95 M (mm) M8 L (mm) 72 B (mm) 64 Ts Nm 41 T Nm 6619 F kN 203 p N/mm2 98 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£61.50
