Drivelock Bushes
-
Drivelock 11 70x110mm (DL11/70)
Drivelock 11 Bushes are self centering, offer very high torques 784 to 419860 Nm and are available in bores from 25 to 300mmDrivelock 11 70x110mm (DL11/70) Part No. 7930-026 Code. DL11/70 d (h8) (mm) 70 D (mm) 110 M (mm) M8 L (mm) 88 B (mm) 78 Ts Nm 83 T Nm 11277 F kN 322 p N/mm2 111 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£77.22
-
Drivelock 11 75x115mm (DL11/75)
Drivelock 11 Bushes are self centering, offer very high torques 784 to 419860 Nm and are available in bores from 25 to 300mmDrivelock 11 75x115mm (DL11/75) Part No. 7930-027 Code. DL11/75 d (h8) (mm) 75 D (mm) 115 M (mm) M10 L (mm) 88 B (mm) 78 Ts Nm 83 T Nm 12062 F kN 322 p N/mm2 111 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£81.50
-
Drivelock 11 80x120 mm (DL11/80)
Drivelock 11 Bushes are self centering, offer very high torques 784 to 419860 Nm and are available in bores from 25 to 300mmDrivelock 11 80x120 mm (DL11/80) Part No. 7930-028 Code. DL11/80 d (h8) (mm) 80 D (mm) 120 M (mm) M10 L (mm) 88 B (mm) 78 Ts Nm 83 T Nm 14219 F kN 355 p N/mm2 112 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£85.83
-
Drivelock 11 85x125mm (DL11/85)
Drivelock 11 Bushes are self centering, offer very high torques 784 to 419860 Nm and are available in bores from 25 to 300mmDrivelock 11 85x125mm (DL11/85) Part No. 7930-029 Code. DL11/85 d (h8) (mm) 85 D (mm) 125 M (mm) M10 L (mm) 88 B (mm) 78 Ts Nm 83 T Nm 15102 F kN 355 p N/mm2 112 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£90.70
-
Drivelock 11 90x130mm (DL11/90)
Drivelock 11 Bushes are self centering, offer very high torques 784 to 419860 Nm and are available in bores from 25 to 300mmDrivelock 11 90x130mm (DL11/90) Part No. 7930-030 Code. DL11/90 d (h8) (mm) 90 D (mm) 130 M (mm) M10 L (mm) 88 B (mm) 78 Ts Nm 83 T Nm 17455 F kN 382 p N/mm2 112 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£94.47
-
Drivelock 11 95x135mm (DL11/95)
Drivelock 11 Bushes are self centering, offer very high torques 784 to 419860 Nm and are available in bores from 25 to 300mmDrivelock 11 95x135mm (DL11/95) Part No. 7930-031 Code. DL11/95 d (h8) (mm) 95 D (mm) 135 M (mm) M10 L (mm) 88 B (mm) 78 Ts Nm 83 T Nm 18338 F kN 382 p N/mm2 112 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£106.07
-
Drivelock 13 100x145mm (DL13/100)
Drivelock 13 Bushes are self centering, offer high torques 350 to 46900 Nm and are available in bores from 18 to 180mmDrivelock 13 100x145mm (DL13/100) Part No. 7930-101 Code DL13/100 d (h8) (mm) 100 D (mm) 145 M (screws)(mm) M12 L (mm) 56 B (mm) 44 Ts (Nm) 125 T(Nm) 13380 F (kN) 268 p (N/mm2) 188 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£47.68
-
Drivelock 13 110x155mm (DL13/110)
Drivelock 13 Bushes are self centering, offer high torques 350 to 46900 Nm and are available in bores from 18 to 180mmDrivelock 13 110x155mm (DL13/110) Part No. 7930-102 Code DL13/110 d (h8) (mm) 110 D (mm) 155 M (screws)(mm) M12 L (mm) 56 B (mm) 44 Ts (Nm) 125 T(Nm) 14580 F (kN) 268 p (N/mm2) 178 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£54.81
-
Drivelock 13 120x165mm (DL13/120)
Drivelock 13 Bushes are self centering, offer high torques 350 to 46900 Nm and are available in bores from 18 to 180mmDrivelock 13 120x165mm (DL13/120) Part No. 7930-103 Code DL13/120 d (h8) (mm) 120 D (mm) 165 M (screws)(mm) M12 L (mm) 56 B (mm) 44 Ts (Nm) 125 T(Nm) 17880 F (kN) 298 p (N/mm2) 178 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£58.89
-
Drivelock 13 18x47mm (DL13/18)
Drivelock 13 Bushes are self centering, offer high torques 350 to 46900 Nm and are available in bores from 18 to 180mmDrivelock 13 18x47mm (DL13/18) Part No. 7930-104 Code DL13/18 d (h8) (mm) 18 D (mm) 47 M (screws)(mm) M6 L (mm) 34 B (mm) 28 Ts (Nm) 14 T(Nm) 350 F (kN) 35 p (N/mm2) 120 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£10.95
-
Drivelock 13 19x47mm (DL13/19)
Drivelock 13 Bushes are self centering, offer high torques 350 to 46900 Nm and are available in bores from 18 to 180mmDrivelock 13 19x47mm (DL13/19) Part No. 7930-105 Code DL13/19 d (h8) (mm) 19 D (mm) 47 M (screws)(mm) M6 L (mm) 34 B (mm) 28 Ts (Nm) 14 T(Nm) 355 F (kN) 35 p (N/mm2) 120 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£10.56
-
Drivelock 13 20x47 mm (DL13/20)
Drivelock 13 Bushes are self centering, offer high torques 350 to 46900 Nm and are available in bores from 18 to 180mmDrivelock 13 20x47 mm (DL13/20) Part No. 7930-106 Code DL13/20 d (h8) (mm) 20 D (mm) 47 M (screws)(mm) M6 L (mm) 34 B (mm) 28 Ts (Nm) 14 T(Nm) 360 F (kN) 38 p (N/mm2) 120 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£10.56
-
Drivelock 13 22x47 mm (DL13/22)
Drivelock 13 Bushes are self centering, offer high torques 350 to 46900 Nm and are available in bores from 18 to 180mmDrivelock 13 22x47 mm (DL13/22) Part No. 7930-107 Code DL13/22 d (h8) (mm) 22 D (mm) 47 M (screws)(mm) M6 L (mm) 34 B (mm) 28 Ts (Nm) 14 T(Nm) 400 F (kN) 38 p (N/mm2) 123 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£10.97
-
Drivelock 13 24x50mm (DL13/24)
Drivelock 13 Bushes are self centering, offer high torques 350 to 46900 Nm and are available in bores from 18 to 180mmDrivelock 13 24x50mm (DL13/24) Part No. 7930-108 Code DL13/24 d (h8) (mm) 24 D (mm) 50 M (screws)(mm) M6 L (mm) 34 B (mm) 28 Ts (Nm) 14 T(Nm) 440 F (kN) 43 p (N/mm2) 120 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£11.40
-
Drivelock 13 25x50 mm (DL13/25)
Drivelock 13 Bushes are self centering, offer high torques 350 to 46900 Nm and are available in bores from 18 to 180mmDrivelock 13 25x50 mm (DL13/25) Part No. 7930-109 Code DL13/25 d (h8) (mm) 25 D (mm) 50 M (screws)(mm) M6 L (mm) 34 B (mm) 28 Ts (Nm) 14 T(Nm) 560 F (kN) 43 p (N/mm2) 138 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£11.40
-
Drivelock 13 28x55mm (DL13/28)
Drivelock 13 Bushes are self centering, offer high torques 350 to 46900 Nm and are available in bores from 18 to 180mmDrivelock 13 28x55mm (DL13/28) Part No. 7930-110 Code DL13/28 d (h8) (mm) 28 D (mm) 55 M (screws)(mm) M6 L (mm) 34 B (mm) 28 Ts (Nm) 14 T(Nm) 625 F (kN) 43 p (N/mm2) 128 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£12.04
-
Drivelock 13 30x55mm (DL13/30)
Drivelock 13 Bushes are self centering, offer high torques 350 to 46900 Nm and are available in bores from 18 to 180mmDrivelock 13 30x55mm (DL13/30) Part No. 7930-111 Code DL13/30 d (h8) (mm) 30 D (mm) 55 M (screws)(mm) M6 L (mm) 34 B (mm) 28 Ts (Nm) 14 T(Nm) 650 F (kN) 43 p (N/mm2) 128 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£12.04
-
Drivelock 13 32x60mm (DL13/32)
Drivelock 13 Bushes are self centering, offer high torques 350 to 46900 Nm and are available in bores from 18 to 180mmDrivelock 13 32x60mm (DL13/32) Part No. 7930-112 Code DL13/32 d (h8) (mm) 32 D (mm) 60 M (screws)(mm) M6 L (mm) 34 B (mm) 28 Ts (Nm) 14 T(Nm) 950 F (kN) 60 p (N/mm2) 150 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£12.28
-
Drivelock 13 35x60mm (DL13/35)
Drivelock 13 Bushes are self centering, offer high torques 350 to 46900 Nm and are available in bores from 18 to 180mmDrivelock 13 35x60mm (DL13/35) Part No. 7930-113 Code DL13/35 d (h8) (mm) 35 D (mm) 60 M (screws)(mm) M6 L (mm) 34 B (mm) 28 Ts (Nm) 14 T(Nm) 1050 F (kN) 60 p (N/mm2) 150 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£13.70
-
Drivelock 13 38x65 mm (DL13/38)
Drivelock 13 Bushes are self centering, offer high torques 350 to 46900 Nm and are available in bores from 18 to 180mmDrivelock 13 38x65 mm (DL13/38) Part No. 7930-114 Code DL13/38 d (h8) (mm) 38 D (mm) 65 M (screws)(mm) M6 L (mm) 34 B (mm) 28 Ts (Nm) 14 T(Nm) 1140 F (kN) 60 p (N/mm2) 146 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£14.24
-
Drivelock 13 40x65mm (DL13/40)
Drivelock 13 Bushes are self centering, offer high torques 350 to 46900 Nm and are available in bores from 18 to 180mmDrivelock 13 40x65mm (DL13/40) Part No. 7930-115 Code DL13/40 d (h8) (mm) 40 D (mm) 65 M (screws)(mm) M6 L (mm) 34 B (mm) 28 Ts (Nm) 14 T(Nm) 1200 F (kN) 60 p (N/mm2) 146 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£14.30
-
Drivelock 13 42x75 mm (DL13/42)
Drivelock 13 Bushes are self centering, offer high torques 350 to 46900 Nm and are available in bores from 18 to 180mmDrivelock 13 42x75 mm (DL13/42) Part No. 7930-116 Code DL13/42 d (h8) (mm) 42 D (mm) 75 M (screws)(mm) M8 L (mm) 41 B (mm) 33 Ts (Nm) 35 T(Nm) 2030 F (kN) 98 p (N/mm2) 168 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£16.08
-
Drivelock 13 45x75mm (DL13/45)
Drivelock 13 Bushes are self centering, offer high torques 350 to 46900 Nm and are available in bores from 18 to 180mmDrivelock 13 45x75mm (DL13/45) Part No. 7930-117 Code DL13/45 d (h8) (mm) 45 D (mm) 75 M (screws)(mm) M8 L (mm) 41 B (mm) 33 Ts (Nm) 35 T(Nm) 2180 F (kN) 98 p (N/mm2) 168 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£16.77
-
Drivelock 13 50x80 mm (DL13/50)
Drivelock 13 Bushes are self centering, offer high torques 350 to 46900 Nm and are available in bores from 18 to 180mmDrivelock 13 50x80 mm (DL13/50) Part No. 7930-118 Code DL13/50 d (h8) (mm) 50 D (mm) 80 M (screws)(mm) M8 L (mm) 41 B (mm) 33 Ts (Nm) 35 T(Nm) 2430 F (kN) 98 p (N/mm2) 158 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£17.82
-
Drivelock 13 55x85mm (DL13/55)
Drivelock 13 Bushes are self centering, offer high torques 350 to 46900 Nm and are available in bores from 18 to 180mmDrivelock 13 55x85mm (DL13/55) Part No. 7930-119 Code DL13/55 d (h8) (mm) 55 D (mm) 85 M (screws)(mm) M8 L (mm) 41 B (mm) 33 Ts (Nm) 35 T(Nm) 3050 F (kN) 112 p (N/mm2) 173 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£19.46
You have seen 50 out of 326 products
