Drivelock Bushes
-
Drivelock 13 60x90mm (DL13/60)
Drivelock 13 Bushes are self centering, offer high torques 350 to 46900 Nm and are available in bores from 18 to 180mmDrivelock 13 60x90mm (DL13/60) Part No. 7930-120 Code DL13/60 d (h8) (mm) 60 D (mm) 90 M (screws)(mm) M8 L (mm) 41 B (mm) 33 Ts (Nm) 35 T(Nm) 3350 F (kN) 112 p (N/mm2) 163 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£20.89
-
Drivelock 13 65x95 mm (DL13/65)
Drivelock 13 Bushes are self centering, offer high torques 350 to 46900 Nm and are available in bores from 18 to 180mmDrivelock 13 65x95 mm (DL13/65) Part No. 7930-121 Code DL13/65 d (h8) (mm) 65 D (mm) 95 M (screws)(mm) M8 L (mm) 41 B (mm) 33 Ts (Nm) 35 T(Nm) 4080 F (kN) 126 p (N/mm2) 173 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£23.86
-
Drivelock 13 70x110mm (DL13/70)
Drivelock 13 Bushes are self centering, offer high torques 350 to 46900 Nm and are available in bores from 18 to 180mmDrivelock 13 70x110mm (DL13/70) Part No. 7930-122 Code DL13/70 d (h8) (mm) 70 D (mm) 110 M (screws)(mm) M10 L (mm) 50 B (mm) 40 Ts (Nm) 70 T(Nm) 6280 F (kN) 179 p (N/mm2) 178 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£31.56
-
Drivelock 13 75x115mm (DL13/75)
Drivelock 13 Bushes are self centering, offer high torques 350 to 46900 Nm and are available in bores from 18 to 180mmDrivelock 13 75x115mm (DL13/75) Part No. 7930-123 Code DL13/75 d (h8) (mm) 75 D (mm) 115 M (screws)(mm) M10 L (mm) 50 B (mm) 40 Ts (Nm) 70 T(Nm) 6680 F (kN) 179 p (N/mm2) 168 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£34.55
-
Drivelock 13 80x120mm (DL13/80)
Drivelock 13 Bushes are self centering, offer high torques 350 to 46900 Nm and are available in bores from 18 to 180mmDrivelock 13 80x120mm (DL13/80) Part No. 7930-124 Code DL13/80 d (h8) (mm) 80 D (mm) 120 M (screws)(mm) M10 L (mm) 50 B (mm) 40 Ts (Nm) 70 T(Nm) 7130 F (kN) 179 p (N/mm2) 158 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£36.31
-
Drivelock 13 85x125mm (DL13/85)
Drivelock 13 Bushes are self centering, offer high torques 350 to 46900 Nm and are available in bores from 18 to 180mmDrivelock 13 85x125mm (DL13/85) Part No. 7930-125 Code DL13/85 d (h8) (mm) 85 D (mm) 125 M (screws)(mm) M10 L (mm) 50 B (mm) 40 Ts (Nm) 70 T(Nm) 8450 F (kN) 200 p (N/mm2) 178 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£38.57
-
Drivelock 13 90x130mm (DL13/90)
Drivelock 13 Bushes are self centering, offer high torques 350 to 46900 Nm and are available in bores from 18 to 180mmDrivelock 13 90x130mm (DL13/90) Part No. 7930-126 Code DL13/90 d (h8) (mm) 90 D (mm) 130 M (screws)(mm) M10 L (mm) 50 B (mm) 40 Ts (Nm) 70 T(Nm) 9080 F (kN) 200 p (N/mm2) 168 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£41.30
-
Drivelock 13 95x135mm (DL13/95)
Drivelock 13 Bushes are self centering, offer high torques 350 to 46900 Nm and are available in bores from 18 to 180mmDrivelock 13 95x135mm (DL13/95) Part No. 7930-127 Code DL13/95 d (h8) (mm) 95 D (mm) 135 M (screws)(mm) M10 L (mm) 50 B (mm) 40 Ts (Nm) 70 T(Nm) 10580 F (kN) 224 p (N/mm2) 178 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£43.94
-
Drivelock 15 14x55mm (DL15/14X55)
Drivelock 15 Bushes are self centering, offer medium torques 282 to 2700 Nm and are available in bores from 14 to 50mmDrivelock 15 14x55mm (DL15/14X55) Part No. 7930-201 Code DL15/14X55 d (h8) (mm) 14 D (mm) 55 D1 (mm) 62 M (mm) M8 L (mm) 39 B (mm) 31 A (mm) 22 Ts (Nm) 41 T (Nm) 282 F (kN) 19 p N/mm2 118 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£10.47
-
Drivelock 15 16x55mm (DL15/16X55)
Drivelock 15 Bushes are self centering, offer medium torques 282 to 2700 Nm and are available in bores from 14 to 50mmDrivelock 15 16x55mm (DL15/16X55) Part No. 7930-202 Code DL15/16X55 d (h8) (mm) 16 D (mm) 55 D1 (mm) 62 M (mm) M8 L (mm) 39 B (mm) 31 A (mm) 22 Ts (Nm) 41 T (Nm) 313 F (kN) 19 p N/mm2 118 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£10.47
-
Drivelock 15 18x55mm (DL15/18X55)
Drivelock 15 Bushes are self centering, offer medium torques 282 to 2700 Nm and are available in bores from 14 to 50mmDrivelock 15 18x55mm (DL15/18X55) Part No. 7930-203 Code DL15/18X55 d (h8) (mm) 18 D (mm) 55 D1 (mm) 62 M (mm) M8 L (mm) 39 B (mm) 31 A (mm) 22 Ts (Nm) 41 T (Nm) 353 F (kN) 19 p N/mm2 118 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£10.83
-
Drivelock 15 19x55mm (DL15/19X55)
Drivelock 15 Bushes are self centering, offer medium torques 282 to 2700 Nm and are available in bores from 14 to 50mmDrivelock 15 19x55mm (DL15/19X55) Part No. 7930-204 Code DL15/19X55 d (h8) (mm) 19 D (mm) 55 D1 (mm) 62 M (mm) M8 L (mm) 39 B (mm) 31 A (mm) 22 Ts (Nm) 41 T (Nm) 372 F (kN) 28 p N/mm2 118 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£10.83
-
Drivelock 15 20x55mm (DL15/20X55)
Drivelock 15 Bushes are self centering, offer medium torques 282 to 2700 Nm and are available in bores from 14 to 50mmDrivelock 15 20x55mm (DL15/20X55) Part No. 7930-205 Code DL15/20X55 d (h8) (mm) 20 D (mm) 55 D1 (mm) 62 M (mm) M8 L (mm) 39 B (mm) 31 A (mm) 22 Ts (Nm) 41 T (Nm) 392 F (kN) 28 p N/mm2 118 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£10.85
-
Drivelock 15 22x55 mm (DL15/22X55)
Drivelock 15 Bushes are self centering, offer medium torques 282 to 2700 Nm and are available in bores from 14 to 50mmDrivelock 15 22x55 mm (DL15/22X55) Part No. 7930-206 Code DL15/22X55 d (h8) (mm) 22 D (mm) 55 D1 (mm) 62 M (mm) M8 L (mm) 39 B (mm) 31 A (mm) 22 Ts (Nm) 41 T (Nm) 431 F (kN) 28 p N/mm2 118 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£10.85
-
Drivelock 15 24x55mm (DL15/24X55)
Drivelock 15 Bushes are self centering, offer medium torques 282 to 2700 Nm and are available in bores from 14 to 50mmDrivelock 15 24x55mm (DL15/24X55) Part No. 7930-207 Code DL15/24X55 d (h8) (mm) 24 D (mm) 55 D1 (mm) 62 M (mm) M8 L (mm) 39 B (mm) 31 A (mm) 22 Ts (Nm) 41 T (Nm) 470 F (kN) 32 p N/mm2 118 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£10.87
-
Drivelock 15 24x65mm (DL15/24X65)
Drivelock 15 Bushes are self centering, offer medium torques 282 to 2700 Nm and are available in bores from 14 to 50mmDrivelock 15 24x65mm (DL15/24X65) Part No. 7930-208 Code DL15/24X65 d (h8) (mm) 24 D (mm) 65 D1 (mm) 72 M (mm) M8 L (mm) 39 B (mm) 31 A (mm) 22 Ts (Nm) 41 T (Nm) 617 F (kN) 33 p N/mm2 122 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£12.04
-
Drivelock 15 25x55 mm (DL15/25X55)
Drivelock 15 Bushes are self centering, offer medium torques 282 to 2700 Nm and are available in bores from 14 to 50mmDrivelock 15 25x55 mm (DL15/25X55) Part No. 7930-209 Code DL15/25X55 d (h8) (mm) 25 D (mm) 55 D1 (mm) 62 M (mm) M8 L (mm) 39 B (mm) 31 A (mm) 22 Ts (Nm) 41 T (Nm) 490 F (kN) 32 p N/mm2 118 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£10.87
-
Drivelock 15 25x65mm (DL15/25X65)
Drivelock 15 Bushes are self centering, offer medium torques 282 to 2700 Nm and are available in bores from 14 to 50mmDrivelock 15 25x65mm (DL15/25X65) Part No. 7930-210 Code DL15/25X65 d (h8) (mm) 25 D (mm) 65 D1 (mm) 72 M (mm) M8 L (mm) 39 B (mm) 31 A (mm) 22 Ts (Nm) 41 T (Nm) 637 F (kN) 33 p N/mm2 122 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£12.04
-
Drivelock 15 28x55 mm (DL15/28X55)
Drivelock 15 Bushes are self centering, offer medium torques 282 to 2700 Nm and are available in bores from 14 to 50mmDrivelock 15 28x55 mm (DL15/28X55) Part No. 7930-211 Code DL15/28X55 d (h8) (mm) 28 D (mm) 55 D1 (mm) 62 M (mm) M8 L (mm) 39 B (mm) 31 A (mm) 22 Ts (Nm) 41 T (Nm) 549 F (kN) 35 p N/mm2 118 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£10.89
-
Drivelock 15 28x65mm (DL15/28X65)
Drivelock 15 Bushes are self centering, offer medium torques 282 to 2700 Nm and are available in bores from 14 to 50mmDrivelock 15 28x65mm (DL15/28X65) Part No. 7930-212 Code DL15/28X65 d (h8) (mm) 28 D (mm) 65 D1 (mm) 72 M (mm) M8 L (mm) 39 B (mm) 31 A (mm) 22 Ts (Nm) 41 T (Nm) 725 F (kN) 37 p N/mm2 122 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£12.08
-
Drivelock 15 30x55mm (DL15/30X55)
Drivelock 15 Bushes are self centering, offer medium torques 282 to 2700 Nm and are available in bores from 14 to 50mmDrivelock 15 30x55mm (DL15/30X55) Part No. 7930-213 Code DL15/30X55 d (h8) (mm) 30 D (mm) 55 D1 (mm) 62 M (mm) M8 L (mm) 39 B (mm) 31 A (mm) 22 Ts (Nm) 41 T (Nm) 588 F (kN) 35 p N/mm2 118 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£10.91
-
Drivelock 15 30x65mm (DL15/30X65)
Drivelock 15 Bushes are self centering, offer medium torques 282 to 2700 Nm and are available in bores from 14 to 50mmDrivelock 15 30x65mm (DL15/30X65) Part No. 7930-214 Code DL15/30X65 d (h8) (mm) 30 D (mm) 65 D1 (mm) 72 M (mm) M8 L (mm) 39 B (mm) 31 A (mm) 22 Ts (Nm) 41 T (Nm) 770 F (kN) 37 p N/mm2 122 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£12.10
-
Drivelock 15 30x80mm (DL15/30X80)
Drivelock 15 Bushes are self centering, offer medium torques 282 to 2700 Nm and are available in bores from 14 to 50mmDrivelock 15 30x80mm (DL15/30X80) Part No. 7930-215 Code DL15/30X80 d (h8) (mm) 30 D (mm) 80 D1 (mm) 87 M (mm) M8 L (mm) 41 B (mm) 33 A (mm) 25 Ts (Nm) 41 T (Nm) 1082 F (kN) 39 p N/mm2 120 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£15.05
-
Drivelock 15 32x65mm (DL15/32X65)
Drivelock 15 Bushes are self centering, offer medium torques 282 to 2700 Nm and are available in bores from 14 to 50mmDrivelock 15 32x65mm (DL15/32X65) Part No. 7930-216 Code DL15/32X65 d (h8) (mm) 32 D (mm) 65 D1 (mm) 72 M (mm) M8 L (mm) 39 B (mm) 31 A (mm) 22 Ts (Nm) 41 T (Nm) 823 F (kN) 45 p N/mm2 122 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£12.10
-
Drivelock 15 32x80mm (DL15/32X80)
Drivelock 15 Bushes are self centering, offer medium torques 282 to 2700 Nm and are available in bores from 14 to 50mmDrivelock 15 32x80mm (DL15/32X80) Part No. 7930-217 Code DL15/32X80 d (h8) (mm) 32 D (mm) 80 D1 (mm) 87 M (mm) M8 L (mm) 41 B (mm) 33 A (mm) 25 Ts (Nm) 41 T (Nm) 1155 F (kN) 49 p N/mm2 120 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£15.09
You have seen 75 out of 326 products
