Drivelock Bushes
-
Drivelock 15 35x65mm (DL15/35X65)
Drivelock 15 Bushes are self centering, offer medium torques 282 to 2700 Nm and are available in bores from 14 to 50mmDrivelock 15 35x65mm (DL15/35X65) Part No. 7930-218 Code DL15/35X65 d (h8) (mm) 35 D (mm) 65 D1 (mm) 72 M (mm) M8 L (mm) 39 B (mm) 31 A (mm) 22 Ts (Nm) 41 T (Nm) 902 F (kN) 45 p N/mm2 122 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£12.08
-
Drivelock 15 35x80 mm (DL15/35X80)
Drivelock 15 Bushes are self centering, offer medium torques 282 to 2700 Nm and are available in bores from 14 to 50mmDrivelock 15 35x80 mm (DL15/35X80) Part No. 7930-219 Code DL15/35X80 d (h8) (mm) 35 D (mm) 80 D1 (mm) 87 M (mm) M8 L (mm) 41 B (mm) 33 A (mm) 25 Ts (Nm) 41 T (Nm) 1260 F (kN) 49 p N/mm2 120 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£15.17
-
Drivelock 15 38x65mm (DL15/38X65)
Drivelock 15 Bushes are self centering, offer medium torques 282 to 2700 Nm and are available in bores from 14 to 50mmDrivelock 15 38x65mm (DL15/38X65) Part No. 7930-220 Code DL15/38X65 d (h8) (mm) 38 D (mm) 65 D1 (mm) 72 M (mm) M8 L (mm) 39 B (mm) 31 A (mm) 22 Ts (Nm) 41 T (Nm) 970 F (kN) 45 p N/mm2 122 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£12.18
-
Drivelock 15 38x80mm (DL15/38X80)
Drivelock 15 Bushes are self centering, offer medium torques 282 to 2700 Nm and are available in bores from 14 to 50mmDrivelock 15 38x80mm (DL15/38X80) Part No. 7930-221 Code DL15/38X80 d (h8) (mm) 38 D (mm) 80 D1 (mm) 87 M (mm) M8 L (mm) 41 B (mm) 33 A (mm) 25 Ts (Nm) 41 T (Nm) 1370 F (kN) 63 p N/mm2 120 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£15.21
-
Drivelock 15 40x65 mm (DL15/40X65)
Drivelock 15 Bushes are self centering, offer medium torques 282 to 2700 Nm and are available in bores from 14 to 50mmDrivelock 15 40x65 mm (DL15/40X65) Part No. 7930-222 Code DL15/40X65 d (h8) (mm) 40 D (mm) 65 D1 (mm) 72 M (mm) M8 L (mm) 39 B (mm) 31 A (mm) 22 Ts (Nm) 41 T (Nm) 1029 F (kN) 45 p N/mm2 122 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£12.06
-
Drivelock 15 40x80mm (DL15/40X80)
Drivelock 15 Bushes are self centering, offer medium torques 282 to 2700 Nm and are available in bores from 14 to 50mmDrivelock 15 40x80mm (DL15/40X80) Part No. 7930-223 Code DL15/40X80 d (h8) (mm) 40 D (mm) 80 D1 (mm) 87 M (mm) M8 L (mm) 41 B (mm) 33 A (mm) 25 Ts (Nm) 41 T (Nm) 1440 F (kN) 63 p N/mm2 120 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£15.05
-
Drivelock 15 42x80mm (DL15/42X80)
Drivelock 15 Bushes are self centering, offer medium torques 282 to 2700 Nm and are available in bores from 14 to 50mmDrivelock 15 42x80mm (DL15/42X80) Part No. 7930-224 Code DL15/42X80 d (h8) (mm) 42 D (mm) 80 D1 (mm) 87 M (mm) M8 L (mm) 41 B (mm) 33 A (mm) 25 Ts (Nm) 41 T (Nm) 1510 F (kN) 70 p N/mm2 120 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£13.09
-
Drivelock 15 45x80mm (DL15/45X80)
Drivelock 15 Bushes are self centering, offer medium torques 282 to 2700 Nm and are available in bores from 14 to 50mmDrivelock 15 45x80mm (DL15/45X80) Part No. 7930-225 Code DL15/45X80 d (h8) (mm) 45 D (mm) 80 D1 (mm) 87 M (mm) M8 L (mm) 41 B (mm) 33 A (mm) 25 Ts (Nm) 41 T (Nm) 1620 F (kN) 70 p N/mm2 120 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£13.09
-
Drivelock 15 48x80mm (DL15/48X80)
Drivelock 15 Bushes are self centering, offer medium torques 282 to 2700 Nm and are available in bores from 14 to 50mmDrivelock 15 48x80mm (DL15/48X80) Part No. 7930-226 Code DL15/48X80 d (h8) (mm) 48 D (mm) 80 D1 (mm) 87 M (mm) M8 L (mm) 41 B (mm) 33 A (mm) 25 Ts (Nm) 41 T (Nm) 1735 F (kN) 75 p N/mm2 120 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£15.09
-
Drivelock 15 50x80mm (DL15/50X80)
Drivelock 15 Bushes are self centering, offer medium torques 282 to 2700 Nm and are available in bores from 14 to 50mmDrivelock 15 50x80mm (DL15/50X80) Part No. 7930-227 Code DL15/50X80 d (h8) (mm) 50 D (mm) 80 D1 (mm) 87 M (mm) M8 L (mm) 41 B (mm) 33 A (mm) 25 Ts (Nm) 41 T (Nm) 1806 F (kN) 75 p N/mm2 120 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£15.11
-
Drivelock 16 100x145 mm (DL16/100)
Drivelock 15 Bushes are self centering, offer high torques 264 to 37000 Nm and are available in bores from 18 to 180mmDrivelock 16 100x145 mm (DL16/100) Part No. 7930-301 Code DL16/100 d (h8) (mm) 100 D (mm) 145 D1 (mm) 154 M (mm) M12 L (mm) 56 B (mm) 44 A (mm) 32 Ts (Nm) 145 T (Nm) 10100 F (kN) 201 p N/mm2 135 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£47.60
-
Drivelock 16 110x155 mm (DL16/110)
Drivelock 15 Bushes are self centering, offer high torques 264 to 37000 Nm and are available in bores from 18 to 180mmDrivelock 16 110x155 mm (DL16/110) Part No. 7930-302 Code DL16/110 d (h8) (mm) 110 D (mm) 155 D1 (mm) 164 M (mm) M12 L (mm) 56 B (mm) 44 A (mm) 32 Ts (Nm) 145 T (Nm) 11030 F (kN) 201 p N/mm2 142 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£54.75
-
Drivelock 16 120x165 mm (DL16/120)
Drivelock 15 Bushes are self centering, offer high torques 264 to 37000 Nm and are available in bores from 18 to 180mmDrivelock 16 120x165 mm (DL16/120) Part No. 7930-303 Code DL16/120 d (h8) (mm) 120 D (mm) 165 D1 (mm) 174 M (mm) M12 L (mm) 56 B (mm) 44 A (mm) 32 Ts (Nm) 145 T (Nm) 13600 F (kN) 226 p N/mm2 137 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£58.81
-
Drivelock 16 140x190mm (DL16/140)
Drivelock 15 Bushes are self centering, offer high torques 264 to 37000 Nm and are available in bores from 18 to 180mmDrivelock 16 140x190mm (DL16/140) Part No. 7930-304 Code DL16/140 d (h8) (mm) 140 D (mm) 190 D1 (mm) 199 M (mm) M14 L (mm) 68 B (mm) 54 A (mm) 40 Ts (Nm) 230 T (Nm) 21800 F (kN) 310 p N/mm2 137 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£90.35
-
Drivelock 16 18x47mm (DL16/18)
Drivelock 15 Bushes are self centering, offer high torques 264 to 37000 Nm and are available in bores from 18 to 180mmDrivelock 16 18x47mm (DL16/18) Part No. 7930-305 Code DL16/18 d (h8) (mm) 18 D (mm) 47 D1 (mm) 56 M (mm) M6 L (mm) 34 B (mm) 28 A (mm) 22 Ts (Nm) 17 T (Nm) 264 F (kN) 27 p N/mm2 93 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£10.85
-
Drivelock 16 19x47mm (DL16/19)
Drivelock 15 Bushes are self centering, offer high torques 264 to 37000 Nm and are available in bores from 18 to 180mmDrivelock 16 19x47mm (DL16/19) Part No. 7930-306 Code DL16/19 d (h8) (mm) 19 D (mm) 47 D1 (mm) 56 M (mm) M6 L (mm) 34 B (mm) 28 A (mm) 22 Ts (Nm) 17 T (Nm) 274 F (kN) 27 p N/mm2 93 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£10.87
-
Drivelock 16 20x47mm (DL16/20)
Drivelock 15 Bushes are self centering, offer high torques 264 to 37000 Nm and are available in bores from 18 to 180mmDrivelock 16 20x47mm (DL16/20) Part No. 7930-307 Code DL16/20 d (h8) (mm) 20 D (mm) 47 D1 (mm) 56 M (mm) M6 L (mm) 34 B (mm) 28 A (mm) 22 Ts (Nm) 17 T (Nm) 284 F (kN) 29 p N/mm2 93 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£10.89
-
Drivelock 16 22x47 mm (DL16/22)
Drivelock 15 Bushes are self centering, offer high torques 264 to 37000 Nm and are available in bores from 18 to 180mmDrivelock 16 22x47 mm (DL16/22) Part No. 7930-308 Code DL16/22 d (h8) (mm) 22 D (mm) 47 D1 (mm) 56 M (mm) M6 L (mm) 34 B (mm) 28 A (mm) 22 Ts (Nm) 17 T (Nm) 314 F (kN) 29 p N/mm2 93 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£10.89
-
Drivelock 16 24x50mm (DL16/24)
Drivelock 15 Bushes are self centering, offer high torques 264 to 37000 Nm and are available in bores from 18 to 180mmDrivelock 16 24x50mm (DL16/24) Part No. 7930-309 Code DL16/24 d (h8) (mm) 24 D (mm) 50 D1 (mm) 59 M (mm) M6 L (mm) 34 B (mm) 28 A (mm) 22 Ts (Nm) 17 T (Nm) 401 F (kN) 29 p N/mm2 107 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£11.76
-
Drivelock 16 25x50 mm (DL16/25)
Drivelock 15 Bushes are self centering, offer high torques 264 to 37000 Nm and are available in bores from 18 to 180mmDrivelock 16 25x50 mm (DL16/25) Part No. 7930-310 Code DL16/25 d (h8) (mm) 25 D (mm) 50 D1 (mm) 59 M (mm) M6 L (mm) 34 B (mm) 28 A (mm) 22 Ts (Nm) 17 T (Nm) 441 F (kN) 35 p N/mm2 107 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£11.78
-
Drivelock 16 28x55mm (DL16/28)
Drivelock 15 Bushes are self centering, offer high torques 264 to 37000 Nm and are available in bores from 18 to 180mmDrivelock 16 28x55mm (DL16/28) Part No. 7930-311 Code DL16/28 d (h8) (mm) 28 D (mm) 55 D1 (mm) 64 M (mm) M6 L (mm) 34 B (mm) 28 A (mm) 22 Ts (Nm) 17 T (Nm) 490 F (kN) 35 p N/mm2 98 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£12.02
-
Drivelock 16 30x55 mm (DL16/30)
Drivelock 15 Bushes are self centering, offer high torques 264 to 37000 Nm and are available in bores from 18 to 180mmDrivelock 16 30x55 mm (DL16/30) Part No. 7930-312 Code DL16/30 d (h8) (mm) 30 D (mm) 55 D1 (mm) 64 M (mm) M6 L (mm) 34 B (mm) 28 A (mm) 22 Ts (Nm) 17 T (Nm) 529 F (kN) 35 p N/mm2 98 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£12.04
-
Drivelock 16 32x60mm (DL16/32)
Drivelock 15 Bushes are self centering, offer high torques 264 to 37000 Nm and are available in bores from 18 to 180mmDrivelock 16 32x60mm (DL16/32) Part No. 7930-313 Code DL16/32 d (h8) (mm) 32 D (mm) 60 D1 (mm) 69 M (mm) M6 L (mm) 34 B (mm) 28 A (mm) 22 Ts (Nm) 17 T (Nm) 755 F (kN) 47 p N/mm2 112 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£13.64
-
Drivelock 16 35x60mm (DL16/35)
Drivelock 15 Bushes are self centering, offer high torques 264 to 37000 Nm and are available in bores from 18 to 180mmDrivelock 16 35x60mm (DL16/35) Part No. 7930-314 Code DL16/35 d (h8) (mm) 35 D (mm) 60 D1 (mm) 69 M (mm) M6 L (mm) 34 B (mm) 28 A (mm) 22 Ts (Nm) 17 T (Nm) 824 F (kN) 47 p N/mm2 107 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£13.66
-
Drivelock 16 38x65mm (DL16/38)
Drivelock 15 Bushes are self centering, offer high torques 264 to 37000 Nm and are available in bores from 18 to 180mmDrivelock 16 38x65mm (DL16/38) Part No. 7930-315 Code DL16/38 d (h8) (mm) 38 D (mm) 65 D1 (mm) 74 M (mm) M6 L (mm) 34 B (mm) 28 A (mm) 22 Ts (Nm) 17 T (Nm) 892 F (kN) 47 p N/mm2 112 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£14.28
You have seen 100 out of 326 products
