Metric Pilot Bore Timing Pulleys
-
Aluminium Pulley T5/22-2 For 16mm Belt (27T5/22-2)
Timing Pulleys T5 for 16mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T5/22-2 For 16mm Belt (27T5/22-2) Part No. 7802-131 Code 27T5/22-2 Type 1F No. teeth 22 De 34.2 Dp 35 Df 38 Dm 24 F 21 L 27 Bore (d) 6 Max. bore 22 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£5.85
-
Aluminium Pulley T5/24-2 For 16mm Belt (27T5/24-2)
Timing Pulleys T5 for 16mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T5/24-2 For 16mm Belt (27T5/24-2) Part No. 7802-132 Code 27T5/24-2 Type 1F No. teeth 24 De 37.4 Dp 38 Df 42 Dm 26 F 21 L 27 Bore (d) 6 Max. bore 24 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£6.13
-
Aluminium Pulley T5/25-2 For 16mm Belt (27T5/25-2)
Timing Pulleys T5 for 16mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T5/25-2 For 16mm Belt (27T5/25-2) Part No. 7802-133 Code 27T5/25-2 Type 1F No. teeth 25 De 39 Dp 39.8 Df 44 Dm 26 F 21 L 27 Bore (d) 6 Max. bore 25 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£6.61
-
Aluminium Pulley T5/26-2 For 16mm Belt (27T5/26-2)
Timing Pulleys T5 for 16mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T5/26-2 For 16mm Belt (27T5/26-2) Part No. 7802-134 Code 27T5/26-2 Type 1F No. teeth 26 De 40.6 Dp 41.4 Df 44 Dm 26 F 21 L 27 Bore (d) 6 Max. bore 25 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£7.03
-
Aluminium Pulley T5/27-2 For 16mm Belt (27T5/27-2)
Timing Pulleys T5 for 16mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T5/27-2 For 16mm Belt (27T5/27-2) Part No. 7802-135 Code 27T5/27-2 Type 1F No. teeth 27 De 42.2 Dp 43 Df 48 Dm 30 F 21 L 27 Bore (d) 8 Max. bore 27 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£6.66
-
Aluminium Pulley T5/28-2 For 16mm Belt (27T5/28-2)
Timing Pulleys T5 for 16mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T5/28-2 For 16mm Belt (27T5/28-2) Part No. 7802-136 Code 27T5/28-2 Type 1F No. teeth 28 De 43.8 Dp 44.6 Df 48 Dm 32 F 21 L 27 Bore (d) 8 Max. bore 29 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£7.17
-
Aluminium Pulley T5/30-2 For 16mm Belt (27T5/30-2)
Timing Pulleys T5 for 16mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T5/30-2 For 16mm Belt (27T5/30-2) Part No. 7802-137 Code 27T5/30-2 Type 1F No. teeth 30 De 47 Dp 47.8 Df 51 Dm 34 F 21 L 27 Bore (d) 8 Max. bore 33 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£7.59
-
Aluminium Pulley T5/32-2 For 16mm Belt (27T5/32-2)
Timing Pulleys T5 for 16mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T5/32-2 For 16mm Belt (27T5/32-2) Part No. 7802-138 Code 27T5/32-2 Type 1F No. teeth 32 De 50.1 Dp 50.9 Df 54 Dm 38 F 21 L 27 Bore (d) 8 Max. bore 37 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£8.62
-
Aluminium Pulley T5/36-2 For 16mm Belt (27T5/36-2)
Timing Pulleys T5 for 16mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T5/36-2 For 16mm Belt (27T5/36-2) Part No. 7802-139 Code 27T5/36-2 Type 1F No. teeth 36 De 56.5 Dp 57.3 Df 64 Dm 38 F 21 L 27 Bore (d) 8 Max. bore 42 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£9.36
-
Aluminium Pulley T5/40-2 For 16mm Belt (27T5/40-2)
Timing Pulleys T5 for 16mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T5/40-2 For 16mm Belt (27T5/40-2) Part No. 7802-140 Code 27T5/40-2 Type 1F No. teeth 40 De 62.9 Dp 63.7 Df 67 Dm 40 F 21 L 27 Bore (d) 8 Max. bore 47 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£10.53
-
Aluminium Pulley T5/42-2 For 16mm Belt (27T5/42-2)
Timing Pulleys T5 for 16mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T5/42-2 For 16mm Belt (27T5/42-2) Part No. 7802-141 Code 27T5/42-2 Type 1F No. teeth 42 De 66 Dp 66.9 Df 70 Dm 40 F 21 L 27 Bore (d) 8 Max. bore 50 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£11.36
-
Aluminium Pulley T5/44-0 For 16mm Belt (27T5/44-0)
Timing Pulleys T5 for 16mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T5/44-0 For 16mm Belt (27T5/44-0) Part No. 7802-142 Code 27T5/44-0 Type 2 No. teeth 44 De 69.2 Dp 70 Df Dm 45 F 21 L 27 Bore (d) 8 Max. bore 52 No. flanges 0 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£11.75
-
Aluminium Pulley T5/48-0 For 16mm Belt (27T5/48-0)
Timing Pulleys T5 for 16mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T5/48-0 For 16mm Belt (27T5/48-0) Part No. 7802-143 Code 27T5/48-0 Type 2 No. teeth 48 De 75.6 Dp 76.4 Df Dm 50 F 21 L 27 Bore (d) 8 Max. bore 60 No. flanges 0 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£12.68
-
Aluminium Pulley T5/60-0 For 16mm Belt (27T5/60-0)
Timing Pulleys T5 for 16mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T5/60-0 For 16mm Belt (27T5/60-0) Part No. 7802-144 Code 27T5/60-0 Type 2 No. teeth 60 De 94.7 Dp 95.5 Df Dm 65 F 21 L 27 Bore (d) 8 Max. bore 76 No. flanges 0 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£18.24
-
Aluminium Pulley T5/10-2 For 25mm Belt (36T5/10-2)
Timing Pulleys T5 for 25mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T5/10-2 For 25mm Belt (36T5/10-2) Part No. 7802-145 Code 36T5/10-2 Type 1F No. teeth 10 De 15.1 Dp 15.9 Df 20 Dm 8 F 30 L 36 Bore (d) Max. bore 6 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£5.48
-
Aluminium Pulley T5/12-2 For 25mm Belt (36T5/12-2)
Timing Pulleys T5 for 25mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T5/12-2 For 25mm Belt (36T5/12-2) Part No. 7802-146 Code 36T5/12-2 Type 1F No. teeth 12 De 18.3 Dp 19.1 Df 23 Dm 11 F 30 L 36 Bore (d) Max. bore 6 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£4.23
-
Aluminium Pulley T5/14-2 For 25mm Belt (36T5/14-2)
Timing Pulleys T5 for 25mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T5/14-2 For 25mm Belt (36T5/14-2) Part No. 7802-147 Code 36T5/14-2 Type 1F No. teeth 14 De 21.5 Dp 22.3 Df 25 Dm 13 F 30 L 36 Bore (d) Max. bore 8 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£4.83
-
Aluminium Pulley T5/15-2 For 25mm Belt (36T5/15-2)
Timing Pulleys T5 for 25mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T5/15-2 For 25mm Belt (36T5/15-2) Part No. 7802-148 Code 36T5/15-2 Type 1F No. teeth 15 De 23.1 Dp 23.9 Df 28 Dm 16 F 30 L 36 Bore (d) 6 Max. bore 10 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£5.48
-
Aluminium Pulley T5/16-2 For 25mm Belt (36T5/16-2)
Timing Pulleys T5 for 25mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T5/16-2 For 25mm Belt (36T5/16-2) Part No. 7802-149 Code 36T5/16-2 Type 1F No. teeth 16 De 24.6 Dp 25.5 Df 32 Dm 18 F 30 L 36 Bore (d) 6 Max. bore 12 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£5.49
-
Aluminium Pulley T5/18-2 For 25mm Belt (36T5/18-2)
Timing Pulleys T5 for 25mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T5/18-2 For 25mm Belt (36T5/18-2) Part No. 7802-150 Code 36T5/18-2 Type 1F No. teeth 18 De 27.8 Dp 28.7 Df 32 Dm 20 F 30 L 36 Bore (d) 6 Max. bore 16 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£5.68
-
Aluminium Pulley T5/19-2 For 25mm Belt (36T5/19-2)
Timing Pulleys T5 for 25mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T5/19-2 For 25mm Belt (36T5/19-2) Part No. 7802-151 Code 36T5/19-2 Type 1F No. teeth 19 De 29.4 Dp 30.2 Df 36 Dm 22 F 30 L 36 Bore (d) 6 Max. bore 16 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£5.94
-
Aluminium Pulley T5/20-2 For 25mm Belt (36T5/20-2)
Timing Pulleys T5 for 25mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T5/20-2 For 25mm Belt (36T5/20-2) Part No. 7802-152 Code 36T5/20-2 Type 1F No. teeth 20 De 31 Dp 31.8 Df 36 Dm 23 F 30 L 36 Bore (d) 6 Max. bore 18 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£5.97
-
Aluminium Pulley T5/22-2 For 25mm Belt (36T5/22-2)
Timing Pulleys T5 for 25mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T5/22-2 For 25mm Belt (36T5/22-2) Part No. 7802-153 Code 36T5/22-2 Type 1F No. teeth 22 De 34.2 Dp 35 Df 38 Dm 24 F 30 L 36 Bore (d) 6 Max. bore 22 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£6.64
-
Aluminium Pulley T5/24-2 For 25mm Belt (36T5/24-2)
Timing Pulleys T5 for 25mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T5/24-2 For 25mm Belt (36T5/24-2) Part No. 7802-154 Code 36T5/24-2 Type 1F No. teeth 24 De 37.4 Dp 38 Df 42 Dm 26 F 30 L 36 Bore (d) 8 Max. bore 24 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£6.78
-
Aluminium Pulley T5/25-2 For 25mm Belt (36T5/25-2)
Timing Pulleys T5 for 25mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T5/25-2 For 25mm Belt (36T5/25-2) Part No. 7802-155 Code 36T5/25-2 Type 1F No. teeth 25 De 39 Dp 39.8 Df 44 Dm 26 F 30 L 36 Bore (d) 8 Max. bore 25 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£7.18
You have seen 75 out of 292 products
