Metric Spur Gears
-
Steel Spur Gear MOD 1.5 60 Tooth (SS15/60B)
Standard to DIN 867, DIN 3962, DIN 3963, Grade/Quality 9 or Equivalent. Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. Steel EN8, (080M40/080M46) or equivalentSteel Spur Gear MOD 1.5 60 Tooth Part No. 4715-060 Code SS15/60B Type B No. of Teeth 60 Pitch Ø dp 90 Bore Ø H8 15* Hub/Boss Ø dm 60 Outside Ø de 93 O/A Width A 30 Face Width B 17 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur *Normally 15mm bore but may be 16mm by exception
£21.65
-
Hostaform Hostaform Spur Gear MOD 1.5 12 Tooth
Metric Spur Gears in moulded POM . Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. Moulded POM C to DIN 3962/63/67 Grade 12. 20° P.APOM Spur Gear MOD 1.5 12 Tooth Part No. 4715-212 Code WPS15/12B No. of Teeth 12 Pitch Ø B 18 Bore Ø H9 6 Hub/Boss Ø D 14 Outside Ø A 21 O/A Width F 23 Face Width G 12 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£3.18
-
Hostaform Hostaform Spur Gear MOD 1.5 13 Tooth
Metric Spur Gears in moulded POM . Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. Moulded POM C to DIN 3962/63/67 Grade 12. 20° P.APOM Spur Gear MOD 1.5 13 Tooth Part No. 4715-213 Code WPS15/13B No. of Teeth 13 Pitch Ø B 19.5 Bore Ø H9 6 Hub/Boss Ø D 14 Outside Ø A 22.5 O/A Width F 23 Face Width G 12 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£3.45
-
Hostaform Hostaform Spur Gear MOD 1.5 14 Tooth
Metric Spur Gears in moulded POM . Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. Moulded POM C to DIN 3962/63/67 Grade 12. 20° P.APOM Spur Gear MOD 1.5 14 Tooth Part No. 4715-214 Code WPS15/14B No. of Teeth 14 Pitch Ø B 21 Bore Ø H9 6 Hub/Boss Ø D 14 Outside Ø A 24 O/A Width F 23 Face Width G 12 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£3.64
-
Hostaform Hostaform Spur Gear MOD 1.5 15 Tooth
Metric Spur Gears in moulded POM . Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. Moulded POM C to DIN 3962/63/67 Grade 12. 20° P.APOM Spur Gear MOD 1.5 15 Tooth Part No. 4715-215 Code WPS15/15B No. of Teeth 15 Pitch Ø B 22.5 Bore Ø H9 6 Hub/Boss Ø D 14 Outside Ø A 25.5 O/A Width F 23 Face Width G 12 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£3.20
-
Hostaform Hostaform Spur Gear MOD 1.5 16 Tooth
Metric Spur Gears in moulded POM . Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. Moulded POM C to DIN 3962/63/67 Grade 12. 20° P.APOM Spur Gear MOD 1.5 16 Tooth Part No. 4715-216 Code WPS15/16B No. of Teeth 16 Pitch Ø B 24 Bore Ø H9 6 Hub/Boss Ø D 14 Outside Ø A 27 O/A Width F 23 Face Width G 12 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£3.93
-
Hostaform Hostaform Spur Gear MOD 1.5 18 Tooth
Metric Spur Gears in moulded POM . Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. Moulded POM C to DIN 3962/63/67 Grade 12. 20° P.APOM Spur Gear MOD 1.5 18 Tooth Part No. 4715-218 Code WPS15/18B No. of Teeth 18 Pitch Ø B 27 Bore Ø H9 8 Hub/Boss Ø D 17 Outside Ø A 30 O/A Width F 23 Face Width G 12 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£3.64
-
Hostaform Hostaform Spur Gear MOD 1.5 20 Tooth
Metric Spur Gears in moulded POM . Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. Moulded POM C to DIN 3962/63/67 Grade 12. 20° P.APOM Spur Gear MOD 1.5 20 Tooth Part No. 4715-220 Code WPS15/20B No. of Teeth 20 Pitch Ø B 30 Bore Ø H9 8 Hub/Boss Ø D 17 Outside Ø A 33 O/A Width F 23 Face Width G 12 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£3.79
-
Hostaform Hostaform Spur Gear MOD 1.5 24 Tooth
Metric Spur Gears in moulded POM . Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. Moulded POM C to DIN 3962/63/67 Grade 12. 20° P.APOM Spur Gear MOD 1.5 24 Tooth Part No. 4715-224 Code WPS15/24B No. of Teeth 24 Pitch Ø B 36 Bore Ø H9 8 Hub/Boss Ø D 19 Outside Ø A 39 O/A Width F 23 Face Width G 12 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£4.32
-
Hostaform Hostaform Spur Gear MOD 1.5 25 Tooth
Metric Spur Gears in moulded POM . Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. Moulded POM C to DIN 3962/63/67 Grade 12. 20° P.APOM Spur Gear MOD 1.5 25 Tooth Part No. 4715-225 Code WPS15/25B No. of Teeth 25 Pitch Ø B 37.5 Bore Ø H9 8 Hub/Boss Ø D 19 Outside Ø A 40.5 O/A Width F 23 Face Width G 12 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£4.95
-
Hostaform Hostaform Spur Gear MOD 1.5 30 Tooth
Metric Spur Gears in moulded POM . Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. Moulded POM C to DIN 3962/63/67 Grade 12. 20° P.APOM Spur Gear MOD 1.5 30 Tooth Part No. 4715-230 Code WPS15/30B No. of Teeth 30 Pitch Ø B 45 Bore Ø H9 10 Hub/Boss Ø D 24 Outside Ø A 48 O/A Width F 23 Face Width G 12 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£6.38
-
Hostaform Hostaform Spur Gear MOD 1.5 35 Tooth
Metric Spur Gears in moulded POM . Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. Moulded POM C to DIN 3962/63/67 Grade 12. 20° P.APOM Spur Gear MOD 1.5 35 Tooth Part No. 4715-235 Code WPS15/35B No. of Teeth 35 Pitch Ø B 52.5 Bore Ø H9 10 Hub/Boss Ø D 24 Outside Ø A 55.5 O/A Width F 23 Face Width G 12 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£5.97
-
Hostaform Hostaform Spur Gear MOD 1.5 40 Tooth
Metric Spur Gears in moulded POM . Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. Moulded POM C to DIN 3962/63/67 Grade 12. 20° P.APOM Spur Gear MOD 1.5 40 Tooth Part No. 4715-240 Code WPS15/40B No. of Teeth 40 Pitch Ø B 60 Bore Ø H9 10 Hub/Boss Ø D 24 Outside Ø A 63 O/A Width F 23 Face Width G 12 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£7.48
-
Hostaform Hostaform Spur Gear MOD 1.5 50 Tooth
Metric Spur Gears in moulded POM . Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. Moulded POM C to DIN 3962/63/67 Grade 12. 20° P.APOM Spur Gear MOD 1.5 50 Tooth Part No. 4715-250 Code WPS15/50B No. of Teeth 50 Pitch Ø B 75 Bore Ø H9 12 Hub/Boss Ø D 27 Outside Ø A 78 O/A Width F 23 Face Width G 12 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£8.64
-
Hostaform Hostaform Spur Gear MOD 1.5 60 Tooth
Metric Spur Gears in moulded POM . Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. Moulded POM C to DIN 3962/63/67 Grade 12. 20° P.APOM Spur Gear MOD 1.5 60 Tooth Part No. 4715-260 Code WPS15/60B No. of Teeth 60 Pitch Ø B 90 Bore Ø H9 12 Hub/Boss Ø D 27 Outside Ø A 93 O/A Width F 23 Face Width G 12 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£9.66
-
Hostaform Hostaform Spur Gear MOD 1.5 70 Tooth
Metric Spur Gears in moulded POM . Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. Moulded POM C to DIN 3962/63/67 Grade 12. 20° P.APOM Spur Gear MOD 1.5 70 Tooth Part No. 4715-270 Code WPS15/70B No. of Teeth 70 Pitch Ø B 105 Bore Ø H9 12 Hub/Boss Ø D 30 Outside Ø A 108 O/A Width F 23 Face Width G 12 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£9.28
-
Hostaform Hostaform Spur Gear MOD 1.5 80 Tooth
Metric Spur Gears in moulded POM . Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. Moulded POM C to DIN 3962/63/67 Grade 12. 20° P.APOM Spur Gear MOD 1.5 80 Tooth Part No. 4715-280 Code WPS15/80B No. of Teeth 80 Pitch Ø B 120 Bore Ø H9 12 Hub/Boss Ø D 30 Outside Ø A 123 O/A Width F 23 Face Width G 12 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£8.81
-
Hostaform Hostaform Spur Gear MOD 1.5 90 Tooth
Metric Spur Gears in moulded POM . Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. Moulded POM C to DIN 3962/63/67 Grade 12. 20° P.APOM Spur Gear MOD 1.5 90 Tooth Part No. 4715-290 Code WPS15/90B No. of Teeth 90 Pitch Ø B 135 Bore Ø H9 12 Hub/Boss Ø D 30 Outside Ø A 138 O/A Width F 23 Face Width G 12 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£9.11
-
Steel Spur Gear MOD 2 12 Tooth (SS20/12B)
Standard to DIN 867, DIN 3962, DIN 3963, Grade/Quality 9 or Equivalent. Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. Steel EN8, (080M40/080M46) or equivalentSteel Spur Gear MOD 2 12 Tooth Part No. 4720-012 Code SS20/12B Type B No. of Teeth 30 Pitch Ø dp 60 Bore Ø H8 10 Hub/Boss Ø dm 40 Outside Ø de 64 O/A Width A 35 Face Width B 20 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£5.06
-
Steel Spur Gear MOD 2 13 Tooth (SS20/13B)
Standard to DIN 867, DIN 3962, DIN 3963, Grade/Quality 9 or Equivalent. Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. Steel EN8, (080M40/080M46) or equivalentSteel Spur Gear MOD 2 13 Tooth Part No. 4720-013 Code SS20/13B Type B No. of Teeth 12 Pitch Ø dp 24 Bore Ø H8 10 Hub/Boss Ø dm 18 Outside Ø de 28 O/A Width A 35 Face Width B 20 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£6.00
-
Steel Spur Gear MOD 2 14 Tooth (SS20/14B)
Standard to DIN 867, DIN 3962, DIN 3963, Grade/Quality 9 or Equivalent. Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. Steel EN8, (080M40/080M46) or equivalentSteel Spur Gear MOD 2 14 Tooth Part No. 4720-014 Code SS20/14B Type B No. of Teeth 13 Pitch Ø dp 26 Bore Ø H8 10 Hub/Boss Ø dm 19/20 Outside Ø de 30 O/A Width A 35 Face Width B 20 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£5.94
-
Steel Spur Gear MOD 2 15 Tooth (SS20/15B)
Standard to DIN 867, DIN 3962, DIN 3963, Grade/Quality 9 or Equivalent. Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. Steel EN8, (080M40/080M46) or equivalentSteel Spur Gear MOD 2 15 Tooth Part No. 4720-015 Code SS20/15B Type B No. of Teeth 14 Pitch Ø dp 28 Bore Ø H8 10 Hub/Boss Ø dm 20/22 Outside Ø de 32 O/A Width A 35 Face Width B 20 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£6.90
-
Steel Spur Gear MOD 2 16 Tooth (SS20/16B)
Standard to DIN 867, DIN 3962, DIN 3963, Grade/Quality 9 or Equivalent. Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. Steel EN8, (080M40/080M46) or equivalentSteel Spur Gear MOD 2 16 Tooth Part No. 4720-016 Code SS20/16B Type B No. of Teeth 15 Pitch Ø dp 30 Bore Ø H8 10 Hub/Boss Ø dm 22/24 Outside Ø de 34 O/A Width A 35 Face Width B 20 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£7.66
-
Steel Spur Gear MOD 2 18 Tooth (SS20/18B)
Standard to DIN 867, DIN 3962, DIN 3963, Grade/Quality 9 or Equivalent. Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. Steel EN8, (080M40/080M46) or equivalentSteel Spur Gear MOD 2 18 Tooth Part No. 4720-018 Code SS20/18B Type B No. of Teeth 16 Pitch Ø dp 32 Bore Ø H8 10 Hub/Boss Ø dm 24 Outside Ø de 36 O/A Width A 35 Face Width B 20 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£8.13
-
Steel Spur Gear MOD 2 20 Tooth (SS20/20B)
Standard to DIN 867, DIN 3962, DIN 3963, Grade/Quality 9 or Equivalent. Standard tolerances, unless otherwise stated ±0.25mm. All dimensions in mm. Steel EN8, (080M40/080M46) or equivalentSteel Spur Gear MOD 2 20 Tooth Part No. 4720-020 Code SS20/20B Type B No. of Teeth 18 Pitch Ø dp 36 Bore Ø H8 10 Hub/Boss Ø dm 25 Outside Ø de 40 O/A Width A 35 Face Width B 20 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£8.67
You have seen 50 out of 1237 products
