Metric Pilot Bore Timing Pulleys
-
Aluminium Pulley T10/60T-0 For 25mm Belt (40T10/60-0)
Timing Pulleys T10 for 25mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T10/60T-0 For 25mm Belt (40T10/60-0) Part No. 7802-240 Code 40T10/60-0 Type 2 No. teeth 60 De 189 Dp 191 Df Dm 110 F 30 L 40 Bore (d) 16 Max. bore 162 No. flanges 0 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£96.65
-
Aluminium Pulley T10/18T-2 For 32mm Belt (47T10/18-2)
Timing Pulleys T10 for 32mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T10/18T-2 For 32mm Belt (47T10/18-2) Part No. 7802-241 Code 47T10/18-2 Type 1F No. teeth 18 De 55.5 Dp 57.3 Df 60 Dm 40 F 37 L 47 Bore (d) 10 Max. bore 44 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£13.36
-
Aluminium Pulley T10/19T-2 For 32mm Belt (47T10/19-2)
Timing Pulleys T10 for 32mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T10/19T-2 For 32mm Belt (47T10/19-2) Part No. 7802-242 Code 47T10/19-2 Type 1F No. teeth 19 De 58.6 Dp 60.5 Df 66 Dm 44 F 37 L 47 Bore (d) 10 Max. bore 46 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£14.59
-
Aluminium Pulley T10/20T-2 For 32mm Belt (47T10/20-2)
Timing Pulleys T10 for 32mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T10/20T-2 For 32mm Belt (47T10/20-2) Part No. 7802-243 Code 47T10/20-2 Type 1F No. teeth 20 De 61.8 Dp 63.7 Df 66 Dm 46 F 37 L 47 Bore (d) 12 Max. bore 50 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£15.65
-
Aluminium Pulley T10/22T-2 For 32mm Belt (47T10/22-2)
Timing Pulleys T10 for 32mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T10/22T-2 For 32mm Belt (47T10/22-2) Part No. 7802-244 Code 47T10/22-2 Type 1F No. teeth 22 De 68.2 Dp 70 Df 75 Dm 52 F 37 L 47 Bore (d) 12 Max. bore 56 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£19.82
-
Aluminium Pulley T10/24T-2 For 32mm Belt (47T10/24-2)
Timing Pulleys T10 for 32mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T10/24T-2 For 32mm Belt (47T10/24-2) Part No. 7802-245 Code 47T10/24-2 Type 1F No. teeth 24 De 74.6 Dp 76.4 Df 83 Dm 58 F 37 L 47 Bore (d) 12 Max. bore 62 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£22.26
-
Aluminium Pulley T10/25T-2 For 32mm Belt (47T10/25-2)
Timing Pulleys T10 for 32mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T10/25T-2 For 32mm Belt (47T10/25-2) Part No. 7802-246 Code 47T10/25-2 Type 1F No. teeth 25 De 77.8 Dp 79.6 Df 83 Dm 60 F 37 L 47 Bore (d) 12 Max. bore 66 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£22.46
-
Aluminium Pulley T10/26T-2 For 32mm Belt (47T10/26-2)
Timing Pulleys T10 for 32mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T10/26T-2 For 32mm Belt (47T10/26-2) Part No. 7802-247 Code 47T10/26-2 Type 1F No. teeth 26 De 80.9 Dp 82.8 Df 87 Dm 60 F 37 L 47 Bore (d) 12 Max. bore 68 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£25.03
-
Aluminium Pulley T10/27T-2 For 32mm Belt (47T10/27-2)
Timing Pulleys T10 for 32mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T10/27T-2 For 32mm Belt (47T10/27-2) Part No. 7802-248 Code 47T10/27-2 Type 1F No. teeth 27 De 84.1 Dp 85.9 Df 91 Dm 60 F 37 L 47 Bore (d) 12 Max. bore 72 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£27.52
-
Aluminium Pulley T10/28T-2 For 32mm Belt (47T10/28-2)
Timing Pulleys T10 for 32mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T10/28T-2 For 32mm Belt (47T10/28-2) Part No. 7802-249 Code 47T10/28-2 Type 1F No. teeth 28 De 87.3 Dp 89.1 Df 93 Dm 60 F 37 L 47 Bore (d) 12 Max. bore 76 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£27.66
-
Aluminium Pulley T10/30T-2 For 32mm Belt (47T10/30-2)
Timing Pulleys T10 for 32mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T10/30T-2 For 32mm Belt (47T10/30-2) Part No. 7802-250 Code 47T10/30-2 Type 1F No. teeth 30 De 93.7 Dp 95.5 Df 97 Dm 60 F 37 L 47 Bore (d) 12 Max. bore 82 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£33.10
-
Aluminium Pulley T10/32T-2 For 32mm Belt (47T10/32-2)
Timing Pulleys T10 for 32mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T10/32T-2 For 32mm Belt (47T10/32-2) Part No. 7802-251 Code 47T10/32-2 Type 1F No. teeth 32 De 100 Dp 102 Df 106 Dm 65 F 37 L 47 Bore (d) 12 Max. bore 88 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£35.07
-
Aluminium Pulley T10/36T-2 For 32mm Belt (47T10/36-2)
Timing Pulleys T10 for 32mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T10/36T-2 For 32mm Belt (47T10/36-2) Part No. 7802-252 Code 47T10/36-2 Type 1F No. teeth 36 De 113 Dp 115 Df 119 Dm 70 F 37 L 47 Bore (d) 16 Max. bore 98 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£40.78
-
Aluminium Pulley T10/40T-2 For 32mm Belt (47T10/40-2)
Timing Pulleys T10 for 32mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T10/40T-2 For 32mm Belt (47T10/40-2) Part No. 7802-253 Code 47T10/40-2 Type 1F No. teeth 40 De 125 Dp 127 Df 131 Dm 80 F 37 L 47 Bore (d) 16 Max. bore 110 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£50.02
-
Aluminium Pulley T10/44T-0 For 32mm Belt (47T10/44-0)
Timing Pulleys T10 for 32mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T10/44T-0 For 32mm Belt (47T10/44-0) Part No. 7802-254 Code 47T10/44-0 Type 2 No. teeth 44 De 138 Dp 140 Df Dm 88 F 37 L 47 Bore (d) 16 Max. bore 118 No. flanges 0 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£63.65
-
Aluminium Pulley T10/48T-0 For 32mm Belt (47T10/48-0)
Timing Pulleys T10 for 32mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T10/48T-0 For 32mm Belt (47T10/48-0) Part No. 7802-255 Code 47T10/48-0 Type 2 No. teeth 48 De 151 Dp 153 Df Dm 95 F 37 L 47 Bore (d) 16 Max. bore 124 No. flanges 0 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£70.04
-
Aluminium Pulley T10/60T-0 For 32mm Belt (47T10/60-0)
Timing Pulleys T10 for 32mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T10/60T-0 For 32mm Belt (47T10/60-0) Part No. 7802-256 Code 47T10/60-0 Type 2 No. teeth 60 De 189 Dp 191 Df Dm 110 F 37 L 47 Bore (d) 16 Max. bore 162 No. flanges 0 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£99.72
-
Aluminium Pulley T10/18T-2 For 50mm Belt (66T10/18-2)
Timing Pulleys T10 for 50mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T10/18T-2 For 50mm Belt (66T10/18-2) Part No. 7802-257 Code 66T10/18-2 Type 1F No. teeth 18 De 55.5 Dp 57.3 Df 60 Dm 40 F 56 L 66 Bore (d) 10 Max. bore 44 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£17.30
-
Aluminium Pulley T10/19T-2 For 50mm Belt (66T10/19-2)
Timing Pulleys T10 for 50mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T10/19T-2 For 50mm Belt (66T10/19-2) Part No. 7802-258 Code 66T10/19-2 Type 1F No. teeth 19 De 58.6 Dp 60.5 Df 66 Dm 44 F 56 L 66 Bore (d) 10 Max. bore 46 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£18.98
-
Aluminium Pulley T10/20T-2 For 50mm Belt (66T10/20-2)
Timing Pulleys T10 for 50mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T10/20T-2 For 50mm Belt (66T10/20-2) Part No. 7802-259 Code 66T10/20-2 Type 1F No. teeth 20 De 61.8 Dp 63.7 Df 66 Dm 46 F 56 L 66 Bore (d) 12 Max. bore 50 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£20.72
-
Aluminium Pulley T10/22T-2 For 50mm Belt (66T10/22-2)
Timing Pulleys T10 for 50mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T10/22T-2 For 50mm Belt (66T10/22-2) Part No. 7802-260 Code 66T10/22-2 Type 1F No. teeth 22 De 68.2 Dp 70 Df 75 Dm 52 F 56 L 66 Bore (d) 12 Max. bore 56 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£26.21
-
Aluminium Pulley T10/24T-2 For 50mm Belt (66T10/24-2)
Timing Pulleys T10 for 50mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T10/24T-2 For 50mm Belt (66T10/24-2) Part No. 7802-261 Code 66T10/24-2 Type 1F No. teeth 24 De 74.6 Dp 76.4 Df 83 Dm 58 F 56 L 66 Bore (d) 12 Max. bore 62 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£29.62
-
Aluminium Pulley T10/25T-2 For 50mm Belt (66T10/25-2)
Timing Pulleys T10 for 50mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T10/25T-2 For 50mm Belt (66T10/25-2) Part No. 7802-262 Code 66T10/25-2 Type 1F No. teeth 25 De 77.8 Dp 79.6 Df 83 Dm 60 F 56 L 66 Bore (d) 12 Max. bore 66 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£29.96
-
Aluminium Pulley T10/26T-2 For 50mm Belt (66T10/26-2)
Timing Pulleys T10 for 50mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T10/26T-2 For 50mm Belt (66T10/26-2) Part No. 7802-263 Code 66T10/26-2 Type 1F No. teeth 26 De 80.9 Dp 82.8 Df 87 Dm 60 F 56 L 66 Bore (d) 12 Max. bore 68 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£32.10
-
Aluminium Pulley T10/27T-2 For 50mm Belt (66T10/27-2)
Timing Pulleys T10 for 50mm wide belt. Centre drilled or Pilot Bore in aluminium with zinc plated Steel Flange.Aluminium Pulley T10/27T-2 For 50mm Belt (66T10/27-2) Part No. 7802-264 Code 66T10/27-2 Type 1F No. teeth 27 De 84.1 Dp 85.9 Df 91 Dm 60 F 56 L 66 Bore (d) 12 Max. bore 72 No. flanges 2 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£36.71
You have seen 150 out of 292 products
