Drivelock Bushes
-
Drivelock 40 55x85 mm (DL40/55)
Drivelock 40 Bushes are self centering, offer high torques 290 to 66800 Nm and are available in bores from 19 to 220mmDrivelock 40 55x85 mm (DL40/55) Part No. 7930-528 Code DL40/55 d (h8) (mm) 55 D (mm) 85 L1 (mm) 20 L (mm) 24 M (screws) 34 H(mm) M8 Ts Nm 37 T (Nm) 2260 F (kN) 83 p N/mm2 127 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£20.02
-
Drivelock 40 60x90 mm (DL40/60)
Drivelock 40 Bushes are self centering, offer high torques 290 to 66800 Nm and are available in bores from 19 to 220mmDrivelock 40 60x90 mm (DL40/60) Part No. 7930-529 Code DL40/60 d (h8) (mm) 60 D (mm) 90 L1 (mm) 20 L (mm) 24 M (screws) 34 H(mm) M8 Ts Nm 37 T (Nm) 2470 F (kN) 83 p N/mm2 120 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£20.75
-
Drivelock 40 65x95 mm (DL40/65)
Drivelock 40 Bushes are self centering, offer high torques 290 to 66800 Nm and are available in bores from 19 to 220mmDrivelock 40 65x95 mm (DL40/65) Part No. 7930-530 Code DL40/65 d (h8) (mm) 65 D (mm) 95 L1 (mm) 20 L (mm) 24 M (screws) 34 H(mm) M8 Ts Nm 37 T (Nm) 3040 F (kN) 92 p N/mm2 128 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£22.53
-
Drivelock 40 70x110 mm (DL40/70)
Drivelock 40 Bushes are self centering, offer high torques 290 to 66800 Nm and are available in bores from 19 to 220mmDrivelock 40 70x110 mm (DL40/70) Part No. 7930-531 Code DL40/70 d (h8) (mm) 70 D (mm) 110 L1 (mm) 24 L (mm) 28 M (screws) 40 H(mm) M10 Ts Nm 70 T (Nm) 4560 F (kN) 130 p N/mm2 127 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£28.51
-
Drivelock 40 75x115 mm (DL40/75)
Drivelock 40 Bushes are self centering, offer high torques 290 to 66800 Nm and are available in bores from 19 to 220mmDrivelock 40 75x115 mm (DL40/75) Part No. 7930-532 Code DL40/75 d (h8) (mm) 75 D (mm) 115 L1 (mm) 24 L (mm) 28 M (screws) 40 H(mm) M10 Ts Nm 70 T (Nm) 4820 F (kN) 130 p N/mm2 124 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£31.42
-
Drivelock 40 80x120 mm (DL40/80)
Drivelock 40 Bushes are self centering, offer high torques 290 to 66800 Nm and are available in bores from 19 to 220mmDrivelock 40 80x120 mm (DL40/80) Part No. 7930-533 Code DL40/80 d (h8) (mm) 80 D (mm) 120 L1 (mm) 24 L (mm) 28 M (screws) 40 H(mm) M10 Ts Nm 70 T (Nm) 5130 F (kN) 130 p N/mm2 120 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£34.41
-
Drivelock 40 85x125 mm (DL40/85)
Drivelock 40 Bushes are self centering, offer high torques 290 to 66800 Nm and are available in bores from 19 to 220mmDrivelock 40 85x125 mm (DL40/85) Part No. 7930-534 Code DL40/85 d (h8) (mm) 85 D (mm) 125 L1 (mm) 24 L (mm) 28 M (screws) 40 H(mm) M10 Ts Nm 70 T (Nm) 6230 F (kN) 144 p N/mm2 127 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£38.21
-
Drivelock 40 90x130mm (DL40/90)
Drivelock 40 Bushes are self centering, offer high torques 290 to 66800 Nm and are available in bores from 19 to 220mmDrivelock 40 90x130mm (DL40/90) Part No. 7930-535 Code DL40/90 d (h8) (mm) 90 D (mm) 130 L1 (mm) 24 L (mm) 28 M (screws) 40 H(mm) M10 Ts Nm 70 T (Nm) 6520 F (kN) 144 p N/mm2 122 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£39.18
-
Drivelock 40 95x135mm (DL40/95)
Drivelock 40 Bushes are self centering, offer high torques 290 to 66800 Nm and are available in bores from 19 to 220mmDrivelock 40 95x135mm (DL40/95) Part No. 7930-536 Code DL40/95 d (h8) (mm) 95 D (mm) 135 L1 (mm) 24 L (mm) 28 M (screws) 40 H(mm) M10 Ts Nm 70 T (Nm) 7770 F (kN) 164 p N/mm2 133 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£40.81
-
Drivelock 45 18x40 mm (DL45/18)
Drivelock 45 Bushes are not self centering, offer medium torques 190 to 4800 Nm and are available in bores from 18 to 80mmDrivelock 45 18x40 mm (DL45/18) Part No. 7930-601 Code DL45/18 d (h8)(mm) 18 D(mm) 40 L2(mm) 18.5 L(mm) 24.5 L1(mm) 12 M (screws) M6 Ts(Nm) 12 T(Nm) 190 F(kN) 260 p(N/mm 2) 120 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£15.29
-
Drivelock 45 19x41 mm (DL45/19)
Drivelock 45 Bushes are not self centering, offer medium torques 190 to 4800 Nm and are available in bores from 18 to 80mmDrivelock 45 19x41 mm (DL45/19) Part No. 7930-602 Code DL45/19 d (h8)(mm) 19 D(mm) 41 L2(mm) 18.5 L(mm) 24.5 L1(mm) 12 M (screws) M6 Ts(Nm) 12 T(Nm) 210 F(kN) 260 p(N/mm 2) 120 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£15.66
-
Drivelock 45 20x42 mm (DL45/20)
Drivelock 45 Bushes are not self centering, offer medium torques 190 to 4800 Nm and are available in bores from 18 to 80mmDrivelock 45 20x42 mm (DL45/20) Part No. 7930-603 Code DL45/20 d (h8)(mm) 20 D(mm) 42 L2(mm) 18.5 L(mm) 24.5 L1(mm) 12 M (screws) M6 Ts(Nm) 12 T(Nm) 240 F(kN) 250 p(N/mm 2) 120 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£16.45
-
Drivelock 45 24x46 mm (DL45/24)
Drivelock 45 Bushes are not self centering, offer medium torques 190 to 4800 Nm and are available in bores from 18 to 80mmDrivelock 45 24x46 mm (DL45/24) Part No. 7930-604 Code DL45/24 d (h8)(mm) 24 D(mm) 46 L2(mm) 18.5 L(mm) 24.5 L1(mm) 12 M (screws) M6 Ts(Nm) 12 T(Nm) 290 F(kN) 250 p(N/mm 2) 120 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£17.90
-
Drivelock 45 25x47 mm (DL45/25)
Drivelock 45 Bushes are not self centering, offer medium torques 190 to 4800 Nm and are available in bores from 18 to 80mmDrivelock 45 25x47 mm (DL45/25) Part No. 7930-605 Code DL45/25 d (h8)(mm) 25 D(mm) 47 L2(mm) 18.5 L(mm) 24.5 L1(mm) 12 M (screws) M6 Ts(Nm) 12 T(Nm) 330 F(kN) 230 p(N/mm 2) 120 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£18.81
-
Drivelock 45 28x50 mm (DL45/28)
Drivelock 45 Bushes are not self centering, offer medium torques 190 to 4800 Nm and are available in bores from 18 to 80mmDrivelock 45 28x50 mm (DL45/28) Part No. 7930-606 Code DL45/28 d (h8)(mm) 28 D(mm) 50 L2(mm) 18.5 L(mm) 24.5 L1(mm) 12 M (screws) M6 Ts(Nm) 12 T(Nm) 370 F(kN) 220 p(N/mm 2) 120 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£19.17
-
Drivelock 45 30x52 mm (DL45/30)
Drivelock 45 Bushes are not self centering, offer medium torques 190 to 4800 Nm and are available in bores from 18 to 80mmDrivelock 45 30x52 mm (DL45/30) Part No. 7930-607 Code DL45/30 d (h8)(mm) 30 D(mm) 52 L2(mm) 18.5 L(mm) 24.5 L1(mm) 12 M (screws) M6 Ts(Nm) 12 T(Nm) 430 F(kN) 210 p(N/mm 2) 120 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£19.62
-
Drivelock 45 35x57 mm (DL45/35)
Drivelock 45 Bushes are not self centering, offer medium torques 190 to 4800 Nm and are available in bores from 18 to 80mmDrivelock 45 35x57 mm (DL45/35) Part No. 7930-608 Code DL45/35 d (h8)(mm) 35 D(mm) 57 L2(mm) 22 L(mm) 28 L1(mm) 15 M (screws) M6 Ts(Nm) 15 T(Nm) 610 F(kN) 170 p(N/mm 2) 100 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£20.77
-
Drivelock 45 38x60 mm (DL45/38)
Drivelock 45 Bushes are not self centering, offer medium torques 190 to 4800 Nm and are available in bores from 18 to 80mmDrivelock 45 38x60 mm (DL45/38) Part No. 7930-609 Code DL45/38 d (h8)(mm) 38 D(mm) 60 L2(mm) 22 L(mm) 28 L1(mm) 15 M (screws) M6 Ts(Nm) 15 T(Nm) 680 F(kN) 170 p(N/mm 2) 100 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£21.29
-
Drivelock 45 40x62 mm (DL45/40)
Drivelock 45 Bushes are not self centering, offer medium torques 190 to 4800 Nm and are available in bores from 18 to 80mmDrivelock 45 40x62 mm (DL45/40) Part No. 7930-610 Code DL45/40 d (h8)(mm) 40 D(mm) 62 L2(mm) 22 L(mm) 28 L1(mm) 15 M (screws) M6 Ts(Nm) 15 T(Nm) 780 F(kN) 170 p(N/mm 2) 100 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£21.86
-
Drivelock 45 42x70 mm (DL45/42)
Drivelock 45 Bushes are not self centering, offer medium torques 190 to 4800 Nm and are available in bores from 18 to 80mmDrivelock 45 42x70 mm (DL45/42) Part No. 7930-611 Code DL45/42 d (h8)(mm) 42 D(mm) 70 L2(mm) 28 L(mm) 36 L1(mm) 18 M (screws) M8 Ts(Nm) 18 T(Nm) 1480 F(kN) 190 p(N/mm 2) 110 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£22.35
-
Drivelock 45 45x73 mm (DL45/45)
Drivelock 45 Bushes are not self centering, offer medium torques 190 to 4800 Nm and are available in bores from 18 to 80mmDrivelock 45 45x73 mm (DL45/45) Part No. 7930-612 Code DL45/45 d (h8)(mm) 45 D(mm) 73 L2(mm) 28 L(mm) 36 L1(mm) 18 M (screws) M8 Ts(Nm) 18 T(Nm) 1500 F(kN) 210 p(N/mm 2) 130 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£22.89
-
Drivelock 45 48x76 mm (DL45/48)
Drivelock 45 Bushes are not self centering, offer medium torques 190 to 4800 Nm and are available in bores from 18 to 80mmDrivelock 45 48x76 mm (DL45/48) Part No. 7930-613 Code DL45/48 d (h8)(mm) 48 D(mm) 76 L2(mm) 28 L(mm) 36 L1(mm) 18 M (screws) M8 Ts(Nm) 18 T(Nm) 1550 F(kN) 210 p(N/mm 2) 130 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£25.26
-
Drivelock 45 50x78 mm (DL45/50)
Drivelock 45 Bushes are not self centering, offer medium torques 190 to 4800 Nm and are available in bores from 18 to 80mmDrivelock 45 50x78 mm (DL45/50) Part No. 7930-614 Code DL45/50 d (h8)(mm) 50 D(mm) 78 L2(mm) 28 L(mm) 36 L1(mm) 18 M (screws) M8 Ts(Nm) 18 T(Nm) 1650 F(kN) 190 p(N/mm 2) 120 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£27.13
-
Drivelock 45 55x83mm (DL45/55)
Drivelock 45 Bushes are not self centering, offer medium torques 190 to 4800 Nm and are available in bores from 18 to 80mmDrivelock 45 55x83mm (DL45/55) Part No. 7930-615 Code DL45/55 d (h8)(mm) 55 D(mm) 83 L2(mm) 28 L(mm) 36 L1(mm) 18 M (screws) M8 Ts(Nm) 18 T(Nm) 2000 F(kN) 190 p(N/mm 2) 120 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£28.77
-
Drivelock 45 60x88 mm (DL45/60)
Drivelock 45 Bushes are not self centering, offer medium torques 190 to 4800 Nm and are available in bores from 18 to 80mmDrivelock 45 60x88 mm (DL45/60) Part No. 7930-616 Code DL45/60 d (h8)(mm) 60 D(mm) 88 L2(mm) 28 L(mm) 36 L1(mm) 18 M (screws) M8 Ts(Nm) 18 T(Nm) 2350 F(kN) 190 p(N/mm 2) 120 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£32.45
