Drivelock Bushes
-
Drivelock 80 60x77mm (DL80/60)
Drivelock 80 Bushes are self centering for thin walled hubs, offer medium torques 12 to 14800 Nm and are available in bores from 6 to 100mmDrivelock 80 60x77mm (DL80/60) Part No. 7931-126 Code DL80/60 d (mm) 60 D (mm) 77 D1 (mm) 104 A (mm 55 B (mm 81 L (mm 89 M (mm) M8 Ts (Nm) 41 T( Nm) 2569 F (kN) 85 p (N/mm2) 53 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£42.57
-
Drivelock 80 65x84mm (DL80/65)
Drivelock 80 Bushes are self centering for thin walled hubs, offer medium torques 12 to 14800 Nm and are available in bores from 6 to 100mmDrivelock 80 65x84mm (DL80/65) Part No. 7931-127 Code DL80/65 d (mm) 65 D (mm) 84 D1 (mm) 111 A (mm 55 B (mm 81 L (mm 89 M (mm) M8 Ts (Nm) 41 T( Nm) 2786 F (kN) 85 p (N/mm2) 53 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£47.24
-
Drivelock 80 70x90mm (DL80/70)
Drivelock 80 Bushes are self centering for thin walled hubs, offer medium torques 12 to 14800 Nm and are available in bores from 6 to 100mmDrivelock 80 70x90mm (DL80/70) Part No. 7931-128 Code DL80/70 d (mm) 70 D (mm) 90 D1 (mm) 119 A (mm 65 B (mm 96.5 L (mm 106.5 M (mm) M10 Ts (Nm) 83 T( Nm) 4755 F (kN) 136 p (N/mm2) 61 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£58.67
-
Drivelock 80 75x95mm (DL80/75)
Drivelock 80 Bushes are self centering for thin walled hubs, offer medium torques 12 to 14800 Nm and are available in bores from 6 to 100mmDrivelock 80 75x95mm (DL80/75) Part No. 7931-129 Code DL80/75 d (mm) 75 D (mm) 95 D1 (mm) 126 A (mm 65 B (mm 96.5 L (mm 106.5 M (mm) M10 Ts (Nm) 83 T( Nm) 5100 F (kN) 136 p (N/mm2) 57 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£68.61
-
Drivelock 80 8x15mm (DL80/8)
Drivelock 80 Bushes are self centering for thin walled hubs, offer medium torques 12 to 14800 Nm and are available in bores from 6 to 100mmDrivelock 80 8x15mm (DL80/8) Part No. 7931-130 Code DL80/8 d (mm) 8 D (mm) 15 D1 (mm) 27 A (mm 12 B (mm 25.5 L (mm 29.5 M (mm) M4 Ts (Nm) 5 T( Nm) 28 F (kN) 7 p (N/mm2) 104 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£12.63
-
Drivelock 80 80x100mm (DL80/80)
Drivelock 80 Bushes are self centering for thin walled hubs, offer medium torques 12 to 14800 Nm and are available in bores from 6 to 100mmDrivelock 80 80x100mm (DL80/80) Part No. 7931-131 Code DL80/80 d (mm) 80 D (mm) 100 D1 (mm) 131 A (mm 65 B (mm 96.5 L (mm 106.5 M (mm) M10 Ts (Nm) 83 T( Nm) 7250 F (kN) 180 p (N/mm2) 57 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£75.34
-
Drivelock 80 9x16mm (DL80/9)
Drivelock 80 Bushes are self centering for thin walled hubs, offer medium torques 12 to 14800 Nm and are available in bores from 6 to 100mmDrivelock 80 9x16mm (DL80/9) Part No. 7931-132 Code DL80/9 d (mm) 9 D (mm) 16 D1 (mm) 28 A (mm 14 B (mm 27.5 L (mm 31.5 M (mm) M4 Ts (Nm) 5 T( Nm) 31 F (kN) 7 p (N/mm2) 85 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£12.67
-
Drivelock 80 90x112mm (DL80/90)
Drivelock 80 Bushes are self centering for thin walled hubs, offer medium torques 12 to 14800 Nm and are available in bores from 6 to 100mmDrivelock 80 90x112mm (DL80/90) Part No. 7931-133 Code DL80/90 d (mm) 90 D (mm) 112 D1 (mm) 144 A (mm 65 B (mm 96.5 L (mm 106.5 M (mm) M10 Ts (Nm) 83 T( Nm) 8160 F (kN) 180 p (N/mm2) 57 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£98.86
-
Drivelock 95 17x50mm (DL95/17)
Drivelock 95 For connection of coaxial shafts, offer medium torques 200 to 4280 Nm and are available in bores from 17 to 80mmDrivelock 95 17x50mm (DL95/17) Part No. 7931-201 Code DL95/17 d (mm) 17* D (mm) 50 B (mm) 50 L (mm) 56 M (mm) M6 Ts (Nm) 17 T (Nm) 200 F (kN) 24 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£20.20
-
Drivelock 95 18x50mm (DL95/18)
Drivelock 95 For connection of coaxial shafts, offer medium torques 200 to 4280 Nm and are available in bores from 17 to 80mmDrivelock 95 18x50mm (DL95/18) Part No. 7931-202 Code DL95/18 d (mm) 18 D (mm) 50 B (mm) 50 L (mm) 56 M (mm) M6 Ts (Nm) 17 T (Nm) 220 F (kN) 24 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£23.98
-
Drivelock 95 19x50mm (DL95/19)
Drivelock 95 For connection of coaxial shafts, offer medium torques 200 to 4280 Nm and are available in bores from 17 to 80mmDrivelock 95 19x50mm (DL95/19) Part No. 7931-203 Code DL95/19 d (mm) 19 D (mm) 50 B (mm) 50 L (mm) 56 M (mm) M6 Ts (Nm) 17 T (Nm) 230 F (kN) 24 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£20.22
-
Drivelock 95 20x50mm (DL95/20)
Drivelock 95 For connection of coaxial shafts, offer medium torques 200 to 4280 Nm and are available in bores from 17 to 80mmDrivelock 95 20x50mm (DL95/20) Part No. 7931-204 Code DL95/20 d (mm) 20 D (mm) 50 B (mm) 50 L (mm) 56 M (mm) M6 Ts (Nm) 17 T (Nm) 240 F (kN) 24 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£20.22
-
Drivelock 95 24x55 mm (DL95/24)
Drivelock 95 For connection of coaxial shafts, offer medium torques 200 to 4280 Nm and are available in bores from 17 to 80mmDrivelock 95 24x55 mm (DL95/24) Part No. 7931-205 Code DL95/24 d (mm) 24 D (mm) 55 B (mm) 60 L (mm) 66 M (mm) M6 Ts (Nm) 17 T (Nm) 290 F (kN) 24 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£21.70
-
Drivelock 95 25x55mm (DL95/25)
Drivelock 95 For connection of coaxial shafts, offer medium torques 200 to 4280 Nm and are available in bores from 17 to 80mmDrivelock 95 25x55mm (DL95/25) Part No. 7931-206 Code DL95/25 d (mm) 25 D (mm) 55 B (mm) 60 L (mm) 66 M (mm) M6 Ts (Nm) 17 T (Nm) 450 F (kN) 36 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£23.19
-
Drivelock 95 28x60mm (DL95/28)
Drivelock 95 For connection of coaxial shafts, offer medium torques 200 to 4280 Nm and are available in bores from 17 to 80mmDrivelock 95 28x60mm (DL95/28) Part No. 7931-207 Code DL95/28 d (mm) 28 D (mm) 60 B (mm) 60 L (mm) 66 M (mm) M6 Ts (Nm) 17 T (Nm) 510 F (kN) 36 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£24.65
-
Drivelock 95 30x60 mm (DL95/30)
Drivelock 95 For connection of coaxial shafts, offer medium torques 200 to 4280 Nm and are available in bores from 17 to 80mmDrivelock 95 30x60 mm (DL95/30) Part No. 7931-208 Code DL95/30 d (mm) 30 D (mm) 60 B (mm) 60 L (mm) 66 M (mm) M6 Ts (Nm) 17 T (Nm) 550 F (kN) 36 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£22.10
-
Drivelock 95 32x63mm (DL95/32)
Drivelock 95 For connection of coaxial shafts, offer medium torques 200 to 4280 Nm and are available in bores from 17 to 80mmDrivelock 95 32x63mm (DL95/32) Part No. 7931-209 Code DL95/32 d (mm) 32 D (mm) 63 B (mm) 60 L (mm) 66 M (mm) M6 Ts (Nm) 17 T (Nm) 580 F (kN) 36 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£29.34
-
Drivelock 95 35x75mm (DL95/35)
Drivelock 95 For connection of coaxial shafts, offer medium torques 200 to 4280 Nm and are available in bores from 17 to 80mmDrivelock 95 35x75mm (DL95/35) Part No. 7931-210 Code DL95/35 d (mm) 35 D (mm) 75 B (mm) 75 L (mm) 83 M (mm) M8 Ts (Nm) 41 T (Nm) 760 F (kN) 45 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£32.75
-
Drivelock 95 38x75mm (DL95/38)
Drivelock 95 For connection of coaxial shafts, offer medium torques 200 to 4280 Nm and are available in bores from 17 to 80mmDrivelock 95 38x75mm (DL95/38) Part No. 7931-211 Code DL95/38 d (mm) 38 D (mm) 75 B (mm) 75 L (mm) 83 M (mm) M8 Ts (Nm) 41 T (Nm) 850 F (kN) 45 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£32.77
-
Drivelock 95 40x75mm (DL95/40)
Drivelock 95 For connection of coaxial shafts, offer medium torques 200 to 4280 Nm and are available in bores from 17 to 80mmDrivelock 95 40x75mm (DL95/40) Part No. 7931-212 Code DL95/40 d (mm) 40 D (mm) 75 B (mm) 75 L (mm) 83 M (mm) M8 Ts (Nm) 41 T (Nm) 900 F (kN) 45 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£32.79
-
Drivelock 95 42x78mm (DL95/42)
Drivelock 95 For connection of coaxial shafts, offer medium torques 200 to 4280 Nm and are available in bores from 17 to 80mmDrivelock 95 42x78mm (DL95/42) Part No. 7931-213 Code DL95/42 d (mm) 42 D (mm) 78 B (mm) 75 L (mm) 83 M (mm) M8 Ts (Nm) 41 T (Nm) 930 F (kN) 45 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£34.43
-
Drivelock 95 45x85mm (DL95/45)
Drivelock 95 For connection of coaxial shafts, offer medium torques 200 to 4280 Nm and are available in bores from 17 to 80mmDrivelock 95 45x85mm (DL95/45) Part No. 7931-214 Code DL95/45 d (mm) 45 D (mm) 85 B (mm) 85 L (mm) 93 M (mm) M8 Ts (Nm) 41 T (Nm) 1520 F (kN) 67 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£38.65
-
Drivelock 95 48x90 mm (DL95/48)
Drivelock 95 For connection of coaxial shafts, offer medium torques 200 to 4280 Nm and are available in bores from 17 to 80mmDrivelock 95 48x90 mm (DL95/48) Part No. 7931-215 Code DL95/48 d (mm) 48 D (mm) 90 B (mm) 85 L (mm) 93 M (mm) M8 Ts (Nm) 41 T (Nm) 1600 F (kN) 67 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£41.42
-
Drivelock 95 50x90mm (DL95/50)
Drivelock 95 For connection of coaxial shafts, offer medium torques 200 to 4280 Nm and are available in bores from 17 to 80mmDrivelock 95 50x90mm (DL95/50) Part No. 7931-216 Code DL95/50 d (mm) 50 D (mm) 90 B (mm) 85 L (mm) 93 M (mm) M8 Ts (Nm) 41 T (Nm) 1690 F (kN) 67 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£41.44
-
Drivelock 95 55x94mm (DL95/55)
Drivelock 95 For connection of coaxial shafts, offer medium torques 200 to 4280 Nm and are available in bores from 17 to 80mmDrivelock 95 55x94mm (DL95/55) Part No. 7931-217 Code DL95/55 d (mm) 55 D (mm) 94 B (mm) 85 L (mm) 93 M (mm) M8 Ts (Nm) 41 T (Nm) 2430 F (kN) 90 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£49.08
You have seen 325 out of 326 products
