Zinc and stainless shaft collars for positioning and load-bearing on round shafts, across a wide bore range.
Shaft Collars
-
Collar 4x16x9mm BZP Single Split (CASB04Z)
En8 zinc plated steel single split Shaft Collars in metric Bore. Type CASB supplied with setscrew(s).Collar 4x16x9mm BZP Single Split (CASB04Z) Part No. 7932-601 Code CASB04Z Bore A (mm) 4 Diameter B (mm) 16 Width C (mm) 9 Clamp Bolt M3X8 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£2.48
-
Collar 5x16x9mm BZP Single Split (CASB05Z)
En8 zinc plated steel single split Shaft Collars in metric Bore. Type CASB supplied with setscrew(s).Collar 5x16x9mm BZP Single Split (CASB05Z) Part No. 7932-602 Code CASB05Z Bore A (mm) 5 Diameter B (mm) 16 Width C (mm) 9 Clamp Bolt M3X8 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£2.72
-
Collar 6x16x9mm BZP Single Split (CASB06Z)
En8 zinc plated steel single split Shaft Collars in metric Bore. Type CASB supplied with setscrew(s).Collar 6x16x9mm BZP Single Split (CASB06Z) Part No. 7932-603 Code CASB06Z Bore A (mm) 6 Diameter B (mm) 16 Width C (mm) 9 Clamp Bolt M3X8 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£2.88
-
Collar 8x18x9mm BZP Single Split (CASB08Z)
En8 zinc plated steel single split Shaft Collars in metric Bore. Type CASB supplied with setscrew(s).Collar 8x18x9mm BZP Single Split (CASB08Z) Part No. 7932-604 Code CASB08Z Bore A (mm) 8 Diameter B (mm) 18 Width C (mm) 9 Clamp Bolt M3X8 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£3.35
-
Collar 9x24x9mm BZP Single Split (CASB09Z)
En8 zinc plated steel single split Shaft Collars in metric Bore. Type CASB supplied with setscrew(s).Collar 9x24x9mm BZP Single Split (CASB09Z) Part No. 7932-605 Code CASB09Z Bore A (mm) 9 Diameter B (mm) 24 Width C (mm) 9 Clamp Bolt M3X10 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£3.21
-
Collar 10x24x9mm BZP Single Split (CASB10Z)
En8 zinc plated steel single split Shaft Collars in metric Bore. Type CASB supplied with setscrew(s).Collar 10x24x9mm BZP Single Split (CASB10Z) Part No. 7932-606 Code CASB10Z Bore A (mm) 10 Diameter B (mm) 24 Width C (mm) 9 Clamp Bolt M3X10 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£3.51
-
Collar 11x28x11mm BZP Single Split (CASB11Z)
En8 zinc plated steel single split Shaft Collars in metric Bore. Type CASB supplied with setscrew(s).Collar 11x28x11mm BZP Single Split (CASB11Z) Part No. 7932-607 Code CASB11Z Bore A (mm) 11 Diameter B (mm) 28 Width C (mm) 11 Clamp Bolt M4X12 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£3.33
-
Collar 12x28x11mm BZP Single Split (CASB12Z)
En8 zinc plated steel single split Shaft Collars in metric Bore. Type CASB supplied with setscrew(s).Collar 12x28x11mm BZP Single Split (CASB12Z) Part No. 7932-608 Code CASB12Z Bore A (mm) 12 Diameter B (mm) 28 Width C (mm) 11 Clamp Bolt M4X12 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£3.58
-
Collar 13x30x11mm BZP Single Split (CASB13Z)
En8 zinc plated steel single split Shaft Collars in metric Bore. Type CASB supplied with setscrew(s).Collar 13x30x11mm BZP Single Split (CASB13Z) Part No. 7932-609 Code CASB13Z Bore A (mm) 13 Diameter B (mm) 30 Width C (mm) 11 Clamp Bolt M4X14 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£3.66
-
Collar 14x30x11mm BZP Single Split (CASB14Z)
En8 zinc plated steel single split Shaft Collars in metric Bore. Type CASB supplied with setscrew(s).Collar 14x30x11mm BZP Single Split (CASB14Z) Part No. 7932-610 Code CASB14Z Bore A (mm) 14 Diameter B (mm) 30 Width C (mm) 11 Clamp Bolt M4X14 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£3.74
-
Collar 15x34x13mm BZP Single Split (CASB15Z)
En8 zinc plated steel single split Shaft Collars in metric Bore. Type CASB supplied with setscrew(s).Collar 15x34x13mm BZP Single Split (CASB15Z) Part No. 7932-611 Code CASB15Z Bore A (mm) 15 Diameter B (mm) 34 Width C (mm) 13 Clamp Bolt M5X16 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£4.70
-
Collar 16x34x13mm BZP Single Split (CASB16Z)
En8 zinc plated steel single split Shaft Collars in metric Bore. Type CASB supplied with setscrew(s).Collar 16x34x13mm BZP Single Split (CASB16Z) Part No. 7932-612 Code CASB16Z Bore A (mm) 16 Diameter B (mm) 34 Width C (mm) 13 Clamp Bolt M5X16 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£4.70
-
Collar 17x36x13mm BZP Single Split (CASB17Z)
En8 zinc plated steel single split Shaft Collars in metric Bore. Type CASB supplied with setscrew(s).Collar 17x36x13mm BZP Single Split (CASB17Z) Part No. 7932-613 Code CASB17Z Bore A (mm) 17 Diameter B (mm) 36 Width C (mm) 13 Clamp Bolt M5X16 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£4.70
-
Collar 18x36x13mm BZP Single Split (CASB18Z)
En8 zinc plated steel single split Shaft Collars in metric Bore. Type CASB supplied with setscrew(s).Collar 18x36x13mm BZP Single Split (CASB18Z) Part No. 7932-614 Code CASB18Z Bore A (mm) 18 Diameter B (mm) 36 Width C (mm) 13 Clamp Bolt M5X16 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£4.70
-
Collar 19x40x15mm BZP Single Split (CASB19Z)
En8 zinc plated steel single split Shaft Collars in metric Bore. Type CASB supplied with setscrew(s).Collar 19x40x15mm BZP Single Split (CASB19Z) Part No. 7932-615 Code CASB19Z Bore A (mm) 19 Diameter B (mm) 40 Width C (mm) 15 Clamp Bolt M5X16 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£4.97
-
Collar 20x40x15mm BZP Single Split (CASB20Z)
En8 zinc plated steel single split Shaft Collars in metric Bore. Type CASB supplied with setscrew(s).Collar 20x40x15mm BZP Single Split (CASB20Z) Part No. 7932-616 Code CASB20Z Bore A (mm) 20 Diameter B (mm) 40 Width C (mm) 15 Clamp Bolt M6X16 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£5.05
-
Collar 24x45x15mm BZP Single Split (CASB24Z)
En8 zinc plated steel single split Shaft Collars in metric Bore. Type CASB supplied with setscrew(s).Collar 24x45x15mm BZP Single Split (CASB24Z) Part No. 7932-617 Code CASB24Z Bore A (mm) 24 Diameter B (mm) 45 Width C (mm) 15 Clamp Bolt M6X16 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£6.81
-
Collar 25x45x15mm BZP Single Split (CASB25Z)
En8 zinc plated steel single split Shaft Collars in metric Bore. Type CASB supplied with setscrew(s).Collar 25x45x15mm BZP Single Split (CASB25Z) Part No. 7932-618 Code CASB25Z Bore A (mm) 25 Diameter B (mm) 45 Width C (mm) 15 Clamp Bolt M6X16 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£6.89
-
Collar 28x48x15mm BZP Single Split (CASB28Z)
En8 zinc plated steel single split Shaft Collars in metric Bore. Type CASB supplied with setscrew(s).Collar 28x48x15mm BZP Single Split (CASB28Z) Part No. 7932-619 Code CASB28Z Bore A (mm) 28 Diameter B (mm) 48 Width C (mm) 15 Clamp Bolt M6X16 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£6.97
-
Collar 30x54x15mm BZP Single Split (CASB30Z)
En8 zinc plated steel single split Shaft Collars in metric Bore. Type CASB supplied with setscrew(s).Collar 30x54x15mm BZP Single Split (CASB30Z) Part No. 7932-620 Code CASB30Z Bore A (mm) 30 Diameter B (mm) 54 Width C (mm) 15 Clamp Bolt M6X18 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£7.19
-
Collar 32x54x15mm BZP Single Split (CASB32Z)
En8 zinc plated steel single split Shaft Collars in metric Bore. Type CASB supplied with setscrew(s).Collar 32x54x15mm BZP Single Split (CASB32Z) Part No. 7932-621 Code CASB32Z Bore A (mm) 32 Diameter B (mm) 54 Width C (mm) 15 Clamp Bolt M6X18 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£7.27
-
Collar 35x57x15mm BZP Single Split (CASB35Z)
En8 zinc plated steel single split Shaft Collars in metric Bore. Type CASB supplied with setscrew(s).Collar 35x57x15mm BZP Single Split (CASB35Z) Part No. 7932-622 Code CASB35Z Bore A (mm) 35 Diameter B (mm) 57 Width C (mm) 15 Clamp Bolt M6X18 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£7.41
-
Collar 38x60x15mm BZP Single Split (CASB38Z)
En8 zinc plated steel single split Shaft Collars in metric Bore. Type CASB supplied with setscrew(s).Collar 38x60x15mm BZP Single Split (CASB38Z) Part No. 7932-623 Code CASB38Z Bore A (mm) 38 Diameter B (mm) 60 Width C (mm) 15 Clamp Bolt M6X18 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£7.86
-
Collar 40x60x15mm BZP Single Split (CASB40Z)
En8 zinc plated steel single split Shaft Collars in metric Bore. Type CASB supplied with setscrew(s).Collar 40x60x15mm BZP Single Split (CASB40Z) Part No. 7932-624 Code CASB40Z Bore A (mm) 40 Diameter B (mm) 60 Width C (mm) 15 Clamp Bolt M6X18 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£8.97
-
Collar 45x73x19mm BZP Single Split (CASB45Z)
En8 zinc plated steel single split Shaft Collars in metric Bore. Type CASB supplied with setscrew(s).Collar 45x73x19mm BZP Single Split (CASB45Z) Part No. 7932-625 Code CASB45Z Bore A (mm) 45 Diameter B (mm) 73 Width C (mm) 19 Clamp Bolt M8X25 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£11.84
You have seen 150 out of 156 products
