Duplex Pilot Bore Sprockets
-
06B-2 36T Steel Sprocket (3DR36)
Duplex 3/8" (06B) British Standard pitch sprocket. Manufactured in Steel EN8, 080M40/080M46, C4506B-2 36T Steel Sprocket (3DR36) Part No. 7822-129 Code 3DR36 No. teeth 36 Outside dia. de 113.4 Pitch dia. dp 109.29 Boss dia. 90 Bore D1* 16 Overall Width A 30 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£11.84
-
06B-2 38T Duplex Steel Sprocket (3DR38)
Duplex 3/8" (06B) British Standard pitch sprocket. Manufactured in Steel EN8, 080M40/080M46, C4506B-2 38T Duplex Steel Sprocket (3DR38) Part No. 7822-130 Code 3DR38 No. teeth 38 Outside dia. de 119.5 Pitch dia. dp 115.34 Boss dia. 90 Bore D1* 16 Overall Width A 30 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£13.38
-
06B-2 38T Duplex Cast Iron Sprocket (3DR38C)
Duplex 3/8" (06B) British Standard pitch sprocket. Manufactured in cast iron.06B-2 38T Duplex Cast Iron Sprocket (3DR38C) Part No. 7822-131 Code 3DR38C No. teeth 38 Outside dia. de 119.5 Pitch dia. dp 115.34 Boss dia. 80 Bore D1* 19 Overall Width A 40 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£23.43
-
06B-2 40T Duplex Steel Sprocket (3DR40)
Duplex 3/8" (06B) British Standard pitch sprocket. Manufactured in Steel EN8, 080M40/080M46, C4506B-2 40T Duplex Steel Sprocket (3DR40) Part No. 7822-132 Code 3DR40 No. teeth 40 Outside dia. de 125.5 Pitch dia. dp 121.4 Boss dia. 90 Bore D1* 16 Overall Width A 30 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£19.16
-
06B-2 45T Duplex Cast Iron Sprocket (3DR45C)
Duplex 3/8" (06B) British Standard pitch sprocket. Manufactured in cast iron.06B-2 45T Duplex Cast Iron Sprocket (3DR45C) Part No. 7822-134 Code 3DR45C No. teeth 45 Outside dia. de 140.7 Pitch dia. dp 136.54 Boss dia. 80 Bore D1* 19 Overall Width A 40 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£29.37
-
06B-2 57T Duplex Steel Sprocket (3DR57)
Duplex 3/8" (06B) British Standard pitch sprocket. Manufactured in Steel EN8, 080M40/080M46, C4506B-2 57T Duplex Steel Sprocket (3DR57) Part No. 7822-136 Code 3DR57 No. teeth 57 Outside dia. de 176.9 Pitch dia. dp 172.91 Boss dia. 88 Bore D1* 20 Overall Width A 50 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£41.56
-
06B-2 57T Duplex Cast Iron Sprocket (3DR57C)
Duplex 3/8" (06B) British Standard pitch sprocket. Manufactured in cast iron.06B-2 57T Duplex Cast Iron Sprocket (3DR57C) Part No. 7822-137 Code 3DR57C No. teeth 57 Outside dia. de 176.9 Pitch dia. dp 172.91 Boss dia. 80 Bore D1* 19 Overall Width A 40 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£37.11
-
06B-2 76T Duplex Cast Iron Sprocket (3DR76C)
Duplex 3/8" (06B) British Standard pitch sprocket. Manufactured in cast iron.06B-2 76T Duplex Cast Iron Sprocket (3DR76C) Part No. 7822-139 Code 3DR76C No. teeth 76 Outside dia. de 234.9 Pitch dia. dp 230.49 Boss dia. 80 Bore D1* 19 Overall Width A 40 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£50.58
-
06B-2 8T Duplex Steel Sprocket (3DR8)
Duplex 3/8" (06B) British Standard pitch sprocket. Manufactured in Steel EN8, 080M40/080M46, C4506B-2 8T Duplex Steel Sprocket (3DR8) Part No. 7822-140 Code 3DR8 No. teeth 8 Outside dia. de 28 Pitch dia. dp 24.89 Boss dia. 15 Bore D1* 6 Overall Width A 22 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£2.31
-
06B-2 9T Duplex Steel Sprocket (3DR9)
Duplex 3/8" (06B) British Standard pitch sprocket. Manufactured in Steel EN8, 080M40/080M46, C4506B-2 9T Duplex Steel Sprocket (3DR9) Part No. 7822-141 Code 3DR9 No. teeth 9 Outside dia. de 31 Pitch dia. dp 27.85 Boss dia. 18 Bore D1* 8 Overall Width A 22 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£3.09
-
06B-2 95T Duplex Cast Iron Sprocket (3DR95C)
Duplex 3/8" (06B) British Standard pitch sprocket. Manufactured in cast iron.06B-2 95T Duplex Cast Iron Sprocket (3DR95C) Part No. 7822-142 Code 3DR95C No. teeth *95 Outside dia. de 292.5 Pitch dia. dp 288.08 Boss dia. 90 Bore D1* 19 Overall Width A 45 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£63.27
-
06B-2 114T Duplex Cast Iron Sprocket (3DR114C)
Duplex 3/8" (06B) British Standard pitch sprocket. Manufactured in cast iron.06B-2 114T Duplex Cast Iron Sprocket (3DR114C) Part No. 7822-143 Code 3DR114C No. teeth *114 Outside dia. de 349.6 Pitch dia. dp 345.68 Boss dia. 90 Bore D1* 19 Overall Width A 45 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£91.96
-
08B-2 10T Duplex Steel Sprocket (4DR10)
Duplex 1/2" (08B) British Standard pitch sprocket. Manufactured in Steel EN8, 080M40/080M46, C4508B-2 10T Duplex Steel Sprocket (4DR10) Part No. 7823-101 Code 4DR10 No. teeth 10 Outside dia. de 45.2 Pitch dia. dp 41.1 Boss dia. 28 Bore D1* 10 Overall Width A 32 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£3.24
-
08B-2 11T Duplex Steel Sprocket (4DR11)
Duplex 1/2" (08B) British Standard pitch sprocket. Manufactured in Steel EN8, 080M40/080M46, C4508B-2 11T Duplex Steel Sprocket (4DR11) Part No. 7823-102 Code 4DR11 No. teeth 11 Outside dia. de 48.7 Pitch dia. dp 45.07 Boss dia. 22 Bore D1* 12 Overall Width A 35 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£4.28
-
08B-2 12T Duplex Steel Sprocket (4DR12)
Duplex 1/2" (08B) British Standard pitch sprocket. Manufactured in Steel EN8, 080M40/080M46, C4508B-2 12T Duplex Steel Sprocket (4DR12) Part No. 7823-105 Code 4DR12 No. teeth 12 Outside dia. de 53 Pitch dia. dp 49.07 Boss dia. 35 Bore D1* 12 Overall Width A 35 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£4.16
-
08B-2 13T Duplex Steel Sprocket (4DR13)
Duplex 1/2" (08B) British Standard pitch sprocket. Manufactured in Steel EN8, 080M40/080M46, C4508B-2 13T Duplex Steel Sprocket (4DR13) Part No. 7823-106 Code 4DR13 No. teeth 13 Outside dia. de 57.4 Pitch dia. dp 53.06 Boss dia. 38 Bore D1* 12 Overall Width A 35 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£4.96
-
08B-2 14T Duplex Steel Sprocket (4DR14)
Duplex 1/2" (08B) British Standard pitch sprocket. Manufactured in Steel EN8, 080M40/080M46, C4508B-2 14T Duplex Steel Sprocket (4DR14) Part No. 7823-107 Code 4DR14 No. teeth 14 Outside dia. de 61.8 Pitch dia. dp 57.07 Boss dia. 42 Bore D1* 12 Overall Width A 35 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£5.74
-
08B-2 15T Duplex Steel Sprocket (4DR15)
Duplex 1/2" (08B) British Standard pitch sprocket. Manufactured in Steel EN8, 080M40/080M46, C4508B-2 15T Duplex Steel Sprocket (4DR15) Part No. 7823-109 Code 4DR15 No. teeth 15 Outside dia. de 65.5 Pitch dia. dp 61.09 Boss dia. 46 Bore D1* 12 Overall Width A 35 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£5.66
-
08B-2 16T Duplex Steel Sprocket (4DR16)
Duplex 1/2" (08B) British Standard pitch sprocket. Manufactured in Steel EN8, 080M40/080M46, C4508B-2 16T Duplex Steel Sprocket (4DR16) Part No. 7823-111 Code 4DR16 No. teeth 16 Outside dia. de 69.5 Pitch dia. dp 65.1 Boss dia. 50 Bore D1* 14 Overall Width A 35 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£5.60
-
08B-2 17T Duplex Steel Sprocket (4DR17)
Duplex 1/2" (08B) British Standard pitch sprocket. Manufactured in Steel EN8, 080M40/080M46, C4508B-2 17T Duplex Steel Sprocket (4DR17) Part No. 7823-112 Code 4DR17 No. teeth 17 Outside dia. de 73.6 Pitch dia. dp 69.11 Boss dia. 54 Bore D1* 14 Overall Width A 35 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£6.40
-
08B-2 18T Duplex Steel Sprocket (4DR18)
Duplex 1/2" (08B) British Standard pitch sprocket. Manufactured in Steel EN8, 080M40/080M46, C4508B-2 18T Duplex Steel Sprocket (4DR18) Part No. 7823-114 Code 4DR18 No. teeth 18 Outside dia. de 77.8 Pitch dia. dp 73.14 Boss dia. 58 Bore D1* 14 Overall Width A 35 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£6.90
-
08B-2 19T Duplex Steel Sprocket (4DR19)
Duplex 1/2" (08B) British Standard pitch sprocket. Manufactured in Steel EN8, 080M40/080M46, C4508B-2 19T Duplex Steel Sprocket (4DR19) Part No. 7823-115 Code 4DR19 No. teeth 19 Outside dia. de 81.7 Pitch dia. dp 77.16 Boss dia. 62 Bore D1* 14 Overall Width A 35 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£7.72
-
08B-2 20T Duplex Steel Sprocket (4DR20)
Duplex 1/2" (08B) British Standard pitch sprocket. Manufactured in Steel EN8, 080M40/080M46, C4508B-2 20T Duplex Steel Sprocket (4DR20) Part No. 7823-117 Code 4DR20 No. teeth 20 Outside dia. de 85.8 Pitch dia. dp 81.19 Boss dia. 66 Bore D1* 14 Overall Width A 35 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£9.36
-
08B-2 21T Duplex Steel Sprocket (4DR21)
Duplex 1/2" (08B) British Standard pitch sprocket. Manufactured in Steel EN8, 080M40/080M46, C4508B-2 21T Duplex Steel Sprocket (4DR21) Part No. 7823-118 Code 4DR21 No. teeth 21 Outside dia. de 89.7 Pitch dia. dp 85.22 Boss dia. 70 Bore D1* 16 Overall Width A 40 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£9.92
-
08B-2 22T Duplex Steel Sprocket (4DR22)
Duplex 1/2" (08B) British Standard pitch sprocket. Manufactured in Steel EN8, 080M40/080M46, C4508B-2 22T Duplex Steel Sprocket (4DR22) Part No. 7823-120 Code 4DR22 No. teeth 22 Outside dia. de 93.8 Pitch dia. dp 89.24 Boss dia. 70 Bore D1* 16 Overall Width A 40 Every effort is taken to ensure the accuracy of the table data Design variations and errors although rare may occur
£10.34
You have seen 50 out of 225 products
